10
SWING OPERATION
Begin air conditioner operation before performing this procedure.
Up/down swing operation Left/right swing operation
Swing operation stops Up/down/left/right swing operation
To select SWING Operation
Press the SWING button.
Each time the SWING button is pressed, the swing operation will change in the
following order.
To stop SWING Operation
Press the SWING button and select STOP.
Airflow direction will return to the setting before swing was begun.
About Swing Operation
The type of operation
Cooling/Dry
Heating
FAN
Range of swing
1 to 5 (All range)
1 to 5 (All range)
1 to 5 (All range)
● The SWING operation may stop temporarily when the air
conditioner’s fan is not operating, or when operating at
very low speeds.
● To select Left/right swing operation
*1
The position of the louvers before swing is given in
parenthesis.
The type of operation
Cooling/Dry
Heating
FAN (1 ~ 4)
*1
FAN (5 ~ 7)
*1
Range of swing
1 to 4
3 to 7
1 to 4
3 to 7
● The SWING operation may stop temporarily when the air
conditioner’s fan is not operating, or when operating at
very low speeds.
● To select Up/down swing operation
ECONOMY OPERATION
Begin Air Conditioner operation before performing this procedure.
To Use the ECONOMY Operation
Press the ECONOMY button.
“ECO” appears on the Remote Controller display.
Economy operation begins.
To Stop the ECONOMY Operation
Press the ECONOMY button again.
“ECO” disappears from the Remote Controller display.
Normal operation begins.
About ECONOMY Operation
In case of single-type air conditioner at the maximum output, ECONOMY Operation is approximately 70% of normal air condi-
tioner operation for cooling and heating.
During ECONOMY operation, the thermostat setting automatically changes according to the temperature to avoid Unneces-
sary cooling and heating for the most economical operation.
● In that time, the airflow may be weakened or indoor fan may be stopped in sometime. If the room is not cooled (or heated)
well during economy operation, select normal operation.
● Once air conditioner operation is stopped, normal operation begins when the indoor unit is turned on again.
● In case of multi-type air conditioner, the economy operation mode is only available for the set indoor unit.
9374379286-02_OM_en.p65 2/4/10, 9:20 AM10
