For remote control unit holder
installation
Use for air conditioner operation
(AR-JW1)
For remote control unit
For mounting the remote control
unit
9371190013
0600185534
9305642014
301141533125
Remote control unit holder
Tapping screw
Remote control unit
Battery (penlight)
Q'ty
REMOTE CONTROL UNIT
Name and Shape Part No.Application
( 3 x 12)
For indoor side pipe joint
(ABY24LBAJ)
9302812021
Joint pipe-A
Q'ty
OPTIONAL PARTS FOR INDOOR UNIT
Name and Shape Part No.Application
2006.11.17 30
OUTDOOR UNIT
9303029015
313166024302
9370244007
303020200114
Use Part No.
For outdoor unit drain piping
work
Q'ty
1
2
Name and Shape
Drain pipe
Drain cap
For use when connecting
models 9-12 to outdoor port A
For sealing
1
1
Adapter assy
Putty
12.7 mm (1/2 in.)
9.52 mm (3/8 in.)
