Fujitsu ABY24LBAJ User Manual

PARTS LIST
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
INDOOR UNIT
ABY24LBAJ
Ref.
No.
Description
Ord.
Q'ty
Part No.
ABY18LBAJ
69 Louver 9358561010 9358561010
8-1 Air Filter 9358567029 9358567029
34 Capacitor (Fan Motor) 2.3µF/450V 9703306044 9703306044
36-2 Cord Holder Metal 9356362008 9356362008
56 Sirocco Fan Assy 9385258006 9385258006
67 Rubber (Vibration-proof) 9385102002 9385102002
68 Cap, Plastic 9358563007 9358563007
108 Base Assy 9359061038 9359061038
109 Casing, Plastic 9358543009 9358543009
124 Dew Proof Plate 9359196006 9359196006
126 Motor Fixing Table Assy 9358591000 9358591000
127 Drain Hose Assy 9359242000 9359242000
138 Separate Wall-A 9358584002 9358584002
146 Evaporator Assy KB07 9362513036 9362513036
160 Drain Pan Assy 9358568002 9358568002
164 Fan Motor Assy-IN MFA-24JTT --------- 9601527015
164 Fan Motor Assy-IN MFA-18JTT 9601527022 ---------
173 Hanger Bracket-L 9358596005 9358596005
174 Hanger Bracket-R 9358595008 9358595008
184-1 Thermistor Spring-A 313728262708 313728262708
187 Clamp No. 1219 313361271706 313361271706
187-1 Clip (Cable) 9352715006 9352715006
195 Clamp SKB-100 313361275805 313361275805
196-1 Clamp SKB-3M 312300787605 312300787605
223 Control Box 9358600016 9358600016
234 Thermistor Assy-Room 9703299087 9703299087
235 Thermistor Assy-Pipe 9900022020 9900022020
240 Remote Control Unit AR-JW1 9371190013 9371190013
236 Controller PCB Assy 97045577739704557780
(K01AL-0408HSE-F1)(K01AL-040DHSE-F1)
320 Flap (Upper)-F 9358538012 9358538012
321 Flap (Lower) 9358541012 9358541012
338 Motor Fixture 9358594001 9358594001
361
Bushing 9357942001 9357942001
361-2
Bushing-B, Plastic 9358554005 9358554005
361-3
Bushing-C, Plastic 9358553008 9358553008
365-1
Special Screw 9359092001 9359092001
365-2
Special Screw 9359091004 9359091004
381
Locking Spacer, KGLS-4S 313209391506 313209391506
385
Indicator PCB Assy EZ-0964HSE-D 9701873012 9701873012
407
Motor Rod 9358560006 9358560006
408 Louver Link 9358556009 9358556009
416 Insulation (Panel)-A 9358574003 9358574003
417 Insulation (Panel)-B 9358914007 9358914007
418 Insulation (Flap Base) 9358572009 9358572009
262004.09.08
422 Clamp NK-10N 9359183006 9359183006
439 Drain Pan Wire 9358598009 9358598009
443 Arm Bracket 9359281009 9359281009
470 Separate Wall-B 9358585009 9358585009
472 Grille Support 9358602003 9358602003
473 Filter Bracket 9358607008 9358607008
488 Grill-F 9358532010 9358532010

Fujitsu ABY24LBAJ Specifications

General

Brand	Fujitsu
Model	ABY24LBAJ
Category	Air Conditioner
Language	English
