Fujitsu ABY36FBAG User Manual

(m
3
/hr)
FAN MOTOR
POWER SOURCE (V) 230
DISCRIMINATION MFA-45DZM
HI-SPEED (r.p.m.) 1,000
INDOOR UNIT
MED-SPEED (r.p.m.) 900
LO-SPEED (r.p.m.) 750
OUTDOOR
DISCRIMINATION
UNIT
HI-SPEED (r.p.m.) 780
1
SPECIFICATIONS
TYPE COOLING COOLING & HEATING
INDOOR UNIT ABY36FBAG ABY36UBAG
OUTDOOR UNIT AOY36FNAXT AOY36UNAXT
COOLING CAPACITY (kW) 10.5
HEATING CAPACITY
(kW)
------- 11.80
POWER SOURCE
FREQUENCY
COOLING 6.20 5.90
RUNNING CURRENT
(A)
HEATING ------- 6.20
INPUT WATTS
(kW)
COOLING 3.74 3.48
HEATING ------- 3.45
E.E.R. (kW/kW)
COOLING 2.81 3.02
HEATING ------- 3.42
MOISTURE REMOVAL 4.0
AIR CIRCULATION
TYPE
Hermetic type, 2 poles, 3 phase,
Twin Rotary
DISCRIMINATION 5JD420PAA02
ELECTRICAL DATA
COMPRESSOR
( /hr)
ADDITIONAL REFRIGERANT CHARGE (R410A)
PIPE LENGTH
20 m 2,000 g 3,200 g
FULL CHARGE
30 m 2,300 g 3,500 g
AMOUNT
40 m 2,600 g 3,800 g
50 m 2,900 g 4,100 g
ADDITIONAL CHARGE 30 g/m
MAX PIPE HEIGHT 30
MAX PIPE LENGTH (m)
(m)
50
INDOOR UNIT H x W x D (mm)
H x W x D (mm)
240 x 1,660 x 700
OUTDOOR UNIT
DIMENSIONS
INDOOR UNIT GROSS / NET
GROSS / NET
(kg)
(kg)
61 / 48
OUTDOOR UNIT 87 / 80 101 / 94
WEIGHT
MFB-30PTT X 2
2005.07.29
50Hz
1,660
1,165 x 900 x 330
3N 400V
