Fujitsu AGYF09LAC User Manual

2008.04.18
1
INDOOR UNIT
H x W x D
H x W x D
600 x 740 x 200 mm
OUTDOOR UNIT
578 x 790 x 300 mm
DIMENSIONS
INDOOR UNIT
Gross / Net
Gross / Net
17 kg / 14 kg 17 kg / 14 kg17 kg / 14 kg
OUTDOOR UNIT
44 kg / 40 kg
540 x 790 x 290 mm
40 kg / 36 kg40 kg / 36 kg
WEIGHT
SPECIFICATIONS
TYPE
Cooling & heating inverter
INDOOR UNIT
AGYF14LAC
OUTDOOR UNIT
AOYV14LA_
AGYF12LAC
AOYV12LAC
AGYF09LAC
AOYV09LAC
COOLING CAPACITY
4.20 kW
HEATING CAPACITY
5.20 kW
POWER SOURCE
230 V
FREQUENCY
50 Hz
230 V
50 Hz
RUNNING CURRENT
Cooling
5.2 A
Heating
6.4 A
INPUT WATTS
Cooling
1.14 kW
Heating
Cooling
Heating
1.44 kW
E.E.R.
Cooling
3.68 kW/kW
COP
Heating
3.61 kW/kW
MOISTURE REMOVAL
2.1 L/hr
AIR CIRCULATION HIGH
650 m3/hr570 m3/hr
650 m3/hr600 m3/hr
2.60 kW
3.50 kW
2.6 A
3.8 A
0.53 kW
0.79 kW
3.72 kW/kW
3.78 kW/kW
4.91 kW/kW
4.43 kW/kW
1.3 L/hr
230 V
50 Hz
570 m3/hr
600 m3/hr
3.50 kW
4.50 kW
4.4 A
5.5 A
0.94 kW
1.19 kW
1.8 L/hr
FAN MOTOR
COMPRESSOR TYPE
Hermetic type, 4 pole, 3 phase, DC inverter motor, Rotary
DISCRIMINATION
DA130A1F-25F
STANDARD REFRIGERANT
REFRIGERANT TYPE
R410A
1,150 g
POWER SOURCE
230 V230 V 230 V
High speed
1,330 / 1,120 r.p.m.
INDOOR UNIT
cooling
(upper fan / lower fan)
Med speed
1,100 / 930 r.p.m.
Low speed
890 / 750 r.p.m.
Quiet
660 / 560 r.p.m.
1,190 r.p.m. / 1,000 r.p.m.
1,000 r.p.m. / 850 r.p.m.
820 r.p.m. / 690 r.p.m.
660 r.p.m. / 560 r.p.m.
High speed
1,330 / 1,120 r.p.m.
INDOOR UNIT
heating
(upper fan / lower fan)
Med speed
1,100 / 930 r.p.m.
Low speed
860 / 730 r.p.m.
Quiet
660 / 560 r.p.m.
1,240 r.p.m. / 1,040 r.p.m.
1,040 r.p.m. / 880 r.p.m.
840 r.p.m. / 700 r.p.m.
660 r.p.m. / 560 r.p.m.
OUTDOOR UNIT heating
OUTDOOR UNIT cooling
750 r.p.m.760 r.p.m.680 r.p.m.
820 r.p.m.760 r.p.m.760 r.p.m.
ELECTRICAL DATA
INDOOR UNIT
( cooling / heating )
OUTDOOR UNIT ( cool / heat )
Quiet
Low speed
50 dB / 50 dB
22 dB / 22 dB
31 dB / 29 dB
Med speed
High speed
38 dB / 37 dB
44 dB / 43 dB
22 dB / 22 dB
29 dB / 29 dB
35 dB / 35 dB
40 dB / 40 dB
22 dB / 22 dB
29 dB / 29 dB
35 dB / 35 dB
40 dB / 40 dB
48 dB / 49 dB47 dB / 48 dB
NOISE LEVEL
REFRIGERANT
Pipe Length
15 m
1,150 g
FULL CHARGE
20 m
1,250 g
ADDITIONAL CHARGE
20 g/m
MAXIMUM PIPE HEIGHT
15 m
DA89X1C-20FZ
R410A
1,050 g
1,050 g
1,150 g
20 g/m
15 m
DA89X1C-20FZ
R410A
1,050 g
1,050 g
1,150 g
20 g/m
15 m

Fujitsu AGYF09LAC Specifications

General

Brand	Fujitsu
Model	AGYF09LAC
Category	Air Conditioner
Language	English
