En-6
Poor Cooling (or Heating) perfor-
mance:
Did you adjust the room temperature settings (thermostat) correctly?
—
Is the air fi lter dirty?
3
Are the air conditioner’s inlet port or outlet port blocked?
—
Is there a window or door open?
—
In the case of Cooling operation, is a window allowing bright sunlight to enter? (Close the curtains.)
—
In the case of Cooling operation, are there heating apparatus and computers inside the room, or are
there too many people in the room?
—
Is the fan speed set to low?
—
Set the temperature lower than
the room temperature and use it:
Temperature does not fall down well.
Temperature may not fall down depending on the room conditions.
(While high humidity or the room temperature is high.)
3
In the following situations stop operation immediately and get in touch with authorized service personnel.
The problem cannot be solved even when the troubleshooting checks have been performed. ●
The FILTER indicator lamp (red) is fl ashing very fast. ●
The wired remote controller or simple remote controller indicate Er (when connected). ●
It has burning smell. ●
SPECIFICATIONS
MODEL
AS
□A18GALH AS□A24GALH AS□A30GALH
POWER SOURCE 230 V ~ 50 Hz
AVAILABLE VOLTAGE RANGE 198 to 264 V
COOLING CAPACITY [kW] 5.6 7.1 8.0
HEATING CAPACITY [kW] 6.3 8.0 9.0
SOUND PRESSURE LEVEL
HIGH dB [A] 41 48 52
MED dB [A] 39 43 45
LOW dB [A] 35 35 35
DIMENSIONS & WEIGHT
HEIGHT [mm] 320
WIDTH [mm] 998
DEPTH [mm] 228
WEIGHT [kg] 15
Acoustic Noise Information : The maximum sound pressure level is less than 70 dB (A) for both indoor unit and outdoor unit.
According to IEC 704-1 and ISO 3744.
