Fujitsu AOU18RD Service Manual

– 16 –
ASU9RD
PARTS LIST
Ref.
No.
Description
Ord.
Q’ty
Part No.
When you order parts, please make a photocopy of this page
and fill the number of the parts in the “Order” column.
26 BR Sheet 40 x 80 x T5 9305039043
32-1 Control Box-A 9309045019
32-2 Control Box-B 9309046016
32-3 Control Box-C 9309055018
41 Fan Motor Assy -In 9600881026
63 Front Panel Assy w/o Filter 9306817176
64 Capacitor (Fan Motor) 7µF/ 200V 9700468103
65 Flow Control Panel-Z 9306571016
69 Louver-A 9306583019
74 Filter 9306601010
89 Casing Fixture Metal 9307018008
92 Link Plate 9306577018
93 Link-A 9306573010
94 Link-B 9306574017
95 Link-C 9306575014
96 Link-D 9306576011
102 Link Spring 9306610012
108 Base 9306566012
109 Casing 9306569013
127 Drain Hose Assy 9305550029
133 Evaporator Cover 9306606015
146 Evaporator Assy 9308200013
158 Connecting Pipe Assy 9309515017
169 Cross-flow Fan Assy 9307836015
178 Motor Cushion-A (Fan Motor) 9303528006
184-1 Thermistor Spring-A 313728262708
189 Shaft Holder-C 9306628017
217 Capacitor Holder 9309047013
236 Controller PCB Assy 9704124012
EZ00017HSE-F
240 Remote Control Unit AR-FB5 9366645016
INDOOR UNIT
Ref.
No.
Description
Ord.
Q’ty
Part No.
268 Motor Cover-B 9306582012
273 Lamp Cover Holder 9309048010
281 Clamp Metal (Pipe) 9306607012
323 Louver-B 9306584016
385 Indicator PCB Assy GM-60171 1301967016
401 Wall Hook Bracket 9306588014
440 Flow Control Panel-U 9306570019
557 Diffuser Spring 9306611019
652-1 Therm. Holder Pipe 313714262805
759 Intake Grille 9307130052
764 Drain Cap Assy 9304150008
767-1 Bottom Cover-A 9306567019
777 Intake Grille Clamp 9306755010
796 Control Box-D 9309049017
815 Terminal 4P 9703455018
873 Lamp Cover 9306593025
875 Power Supply PCB Assy 9704125019
EZ-00017HSE-P
876-1 Step Motor 9305780006
876-2 Step Motor 9305892006
960 Diffuser 9306572013
962-1 Guard Holder-L 9307229015
962-2 Guard Holder-R 9307228018
963 Fan Guard Metal Rod 9305751020
B Screw(w/Spring Washer) 0700179013
C Control Box Assy 9309044012
D Control Box Cover A 9309039018
E Control Box Cover B 9309040014
F Control Box Cover C 9309041011
G Control Box Cover D 9309042018
H Conduit Holder 9309043015
