Page #26 background imageLoading...
Page #26 background image
5V
5V
5V
+
I C201
GP1UM261RKVF
R202
47
<1/4W>
C202
47/
10V
C203
0.1
<F>
SW201
KSHC611BT
CN201
7 - JB / PL2
L = 230 #26 / 1061
A
A
A
A
1
2
3
4
5
6
7
2
1
3
VCC
OUT
GND
2.5mmP
D201, D203
SLR-343MC
<RED>
x 2
D202
SLR-343DC
<ORANGE>
D201
D202
D203
INDOOR UNIT
COMPACT WALL MOUNTED
ASU7RLF
ASU9RLF
ASU12RLF
INDICATOR PCB ASSEMBLY
K07BJ-0900HSD-D0
