REFRIGERANT SYSTEM DIAGRAM
Models :
Dryer
Refrigerant pipe
15.88 mm (5/8")
Refrigerant pipe
9.52 mm (3/8")
Capillary tube
Charging valve
Compressor
OUTDOOR UNIT
Condenser
INDOOR UNIT
Evaporator
Accumulator
Models :
Refrigerant pipe
15.88mm(5/8")
Refrigerant pipe
9.52mm(3/8")
INDOOR UNIT
Evaporator
Cooling
Heating
: Flare coupling
Check valve
Compressor
Dryer
Muffler
Strainer
Strainer
OUTDOOR UNIT
Condenser
4-Way
valve
Accumulator
Charging valve
ARG25ALC / AOG25ANBL
ARY25ALC / AOY25ANBL
ART25ALC / AOT25ANAL
ARG25RLC / AOG25RNBL
ARY25RLC / AOY25RNBL
ART25RLC / AOT25RNAL
ART25RLC / AOT25RZDL
2003.05.08
15
