Ref.
No.
Description
AOG36EPA3L, AOY36EPA3L AOG45EPA3L, AOY45EPA3L
Part No.
OUT DOOR U N IT
2 Fan Cover 9352159015 9352159015
4 Emblem-Rear(forAOG) 313791088300 313791088300
4 Emblem-Rear(forAOY) 9351355005 9351355005
5 Cabinet-A, Painted 9352146015 9352146015
6 Cabinet-C, Painted 9352149016 9352149016
9 Cabinet-B, Painted 9352147012 9352147012
12 Base Assy, Painted 9352136016 9352136016
15
Dryer
9369978036 9369978036
16 Condenser Assy 9364074009 ------
16-1 Condenser-A Assy ------ 9364064000
16-2 Condenser-B Assy ------ 9364061009
18 Suction Pipe Assy 9370948028 9364514000
19 Capillary Tube 9364083001 9364053004
20 Discharge Pipe Assy ------ 9364132006
26 Compressor Cover-A 9364088006 9364088006
29 Separate Wall 9355277013 9355277013
30 Blower Cover, Painted 9352151019 9352151019
32 Control Box Metal 9352134012 9352134012
36 Cord Holder Metal 9356934007 9356934007
39 Propeller Fan Assy 9300855013 9300855013
41 Fan Motor Assy-Out 9600832028 9600832028
45 Bracket (Motor) Assy 9352141003 9352141003
46 Compressor Assy 9370772012 9367376001
47-2 Rubber (Discharge Pipe) 313185159802 313185159802
48 Bracket (Coupler) Assy 9355281010 9355281010
55 Special Nut M8 (For Comp.) 9355091008 9355091008
107 Rubber Seat-A (For Comp.) 9364084008 9364084008
108 Sleeve-A (For Comp.) 9364085005 9364085005
109 Terminal Cover (For Comp.) 9364087009 9364087009
111 Terminal Packing 9364086002 9364086002
178-2 Capillary Holder Rubber 313394274808 ------
185 Rubber Bushing 313005066051 313005066051
246 Outlet Pipe (Cond.) Assy 9364178004 9364060002
320 Wire Clamp Metal 313483219905 313483219905
333-2 Accumulator (B) 9301942019 9368463007
334 Suction Pipe-B 9364065007 9362557009
34 Capacitor (Fan Motor) 9357965024 9357965024
- 15 -2003.09.22
Ord.
Q'ty
361 Accumulator Support Assy 9355351003 ------
401 Terminal-2P 9701971015 9701971015
405 Clamp No.1763 313816345304 313816345304
407 Clip (Cable) No.1259 313739340109 313739340109
450 Discharge Pipe-A 9370951035 9364079004
527 Protection Net 9352163012 9352163012
549 Thermistor Outdoor 9352426001 9352426001
620 Inlet Pipe (Cond.) Assy 9364068008 9364090009
646 Compressor Cover-B 9364089003 9364089003
734 Cabinet Top Plate 9352161018 9352161018
788 Thermistor-Overheat 93540610029354061002
790-1 Belt Heater-A 9361140066 9361140042
791 Magnetic Relay 9363277005 9363277005
803 Cabinet-D, Painted 9352150012 9352150012
805 Blower Cover Corner 9352160011 9352160011
806 Cond. Pass Pipe-A 9364075006 ------
807 Cond. Pass Pipe-B 9364076003 -----
808 Inlet Pipe (Accumulator) 9364066004 9362558006
809 Ball Valve-A 9371799018 9371799018
810 Ball Valve-B 9371799032 9371799032
373 Grip 9352157004 9352157004
813 Cabinet Hook 9352148002 9352148002
815 Terminal-8P 9363276022 9363276022
816 Wire Clamp Metal 313584219902 313584219902
817 Thermostat Fixture 9352164019 9352164019
818 Accumulator Support-B Assy 9355350006 ------
819 Valve-A Coupl. Pipe 9364081007 9364052007
820 Joint Pipe (Capillary) 9364082004 ------
821 Joint Pipe Assy 9364080000 9362564007
822 Fan Cover Fixture-A 9352158018 9352158018
823-2 Fuse Holder 0500063024 0500063024
824-4 Fuse 0600222529 0600222529
826 Condensing Pipe-B ------ 9364062006
863 Joint Pipe (Capillary)-B ------ 9362563000
880-1 Network 97009870179700987017
