Item no. Part no. Part name Service part

9383735127 Evaporator total assy (for 09-12 model) ♦

9383735134 Evaporator total assy (for 15 model) ♦

51 9387467000 Room thermistor holder ♦

52 9306489045 Terminal ♦

9711141835 Main PCB (for 09 model) ♦

9711141842 Main PCB (for 12 model) ♦

9711141859 Main PCB (for 15 model) ♦

54 9900627041 Thermistor assy ♦

55 9711146014 Display assy ♦

56 9317755061 Pyroelectric sensor ♦

57 9711147011 Indicator PCB ♦

58 9387589054 Motor case assy ♦

59 9603821005 Brushless motor ♦

60 9383565007 Pipe bracket ♦

61 9387488043 Cable guide ♦

62 9387714012 Gear case assy ♦

63 9901011016 Stepping motor ♦

64 9383728006 Vertical louver stepping motor assy ♦

65 9901011023 Stepping motor ♦

66 9387590142 Drain pan total assy ♦

67 9316904002 Drain hose assy ♦

68 9316177017 Drain cap ♦

69 9387591071 Drain pan assy ♦

70 9333628004 Bearing D assy ♦

71 9387055054 Crossflow fan assy ♦

72 9387587081 Base assy ♦

a — Control box —

b — Control cover —

c — Display case —

d — Motor case —

e — Motor cover assy —

2-1. Models: ASUG09LZAS, ASUG12LZAS, and ASUG15LZAS - (02-5) - 2. Indoor unit parts list
