Fujitsu ASUG15LZAS User Manual

1. Specifications
1-1. Indoor unit
Type
Wall mounted
Inverter heat pump
Model name ASUG09LZAS ASUG12LZAS ASUG15LZAS
Power supply 208/230 V ~60 Hz
Power supply intake Outdoor unit
Available voltage range 187—253 V
Capacity
Cooling
Rated
kW 2.64 3.52 4.25
Btu/h 9,000 12,000 14,500
Min.—Max.
kW 0.91—3.52 0.91—3.99 0.91—5.39
Btu/h 3,100—12,000 3,100—13,600 3,100—18,400
Heating
Rated
kW 3.52 4.69 5.28
Btu/h 12,000 16,000 18,000
Min.—Max.
kW 0.91—6.45 0.91—6.48 0.91—7.00
Btu/h 3,100—22,000 3,100—22,100 3,100—23,900
Heating
(17°F)*
1
Rated
kW 2.17 2.93 3.28
Btu/h 7,400 10,000 11,200
Max.
kW 4.69 5.13 6.30
Btu/h 16,000 17,500 21,500
Heating
(5°F)*
2
Rated
kW 4.51 4.87 5.13
Btu/h 15,400 16,600 17,500
Max.
kW 4.51 4.87 6.15
Btu/h 15,400 16,600 21,000
Input power
Cooling
Rated
kW
0.50 0.79 1.04
Min.—Max. 0.11—0.85 0.11—0.99 0.15—1.56
Heating
Rated 0.66 1.01 1.15
Min.—Max. 0.17—1.93 0.17—1.94 0.15—2.19
Heating
(17°F)*
1
Rated 0.60 0.88 1.01
Max. 2.06 2.59
Heating
(5°F)*
2
Rated 2.10 2.09 2.03
Max. 2.10 2.75
Current
Cooling
Rated A
2.5 3.8 4.8
Heating 3.3 4.7 5.2
EER2 Cooling
kW/kW 5.28 4.46 4.09
Btu/hW 18.0 15.2 13.9
COP2 Heating
kW/kW 5.34 4.64 4.60
Btu/hW 18.2 15.8 15.7
SEER2 Cooling Btu/hW 33.1 29.4 25.3
HSPF2 Heating Btu/hW 13.4 12.9 12.8
Power factor
Cooling
%
87 90 94
Heating 87 93 96
Moisture removal pints/h (L/h) 2.5 (1.2) 2.7 (1.3) 4.0 (1.9)
Maximum operating current*
3
Cooling
A
9.4 9.9
Heating 10.9 13.4
Fan
Airflow rate
Cooling
HIGH
CFM (m
3
/h)
542 (920) 583 (990)
MED 406 (690) 459 (780)
LOW 312 (530) 312 (530)
QUIET 206 (350) 241 (410)
Heating
HIGH 542 (920) 600 (1,020)
MED 406 (690) 459 (780)
LOW 312 (530) 312 (530)
QUIET 206 (350) 241 (410)
Type × Qty Crossflow fan × 1
Motor output W 59
Sound pressure level*
4
Cooling
HIGH
dB (A)
43 45
MED 37 40
LOW 31 32
QUIET 23 26
Heating
HIGH 43 45
MED 36 39
LOW 31 32
QUIET 23 26
Heat exchanger type
Dimensions (H × W × D) in (mm)
Main1: 8-1/4 × 31-7/16 × 1-1/16 (210 × 798 × 26.6)
Main2: 5-5/16 × 31-7/16 × 13/16 (135 × 798 × 20.0)
Sub1: 3-5/16 × 31-7/16 × 1/2 (84 × 798 × 13.3)
Sub2: 3-5/16 × 31-7/16 × 1/2 (84 × 798 × 13.3)
Fin pitch FPI
Man 1: 21
Main 2: 23
Sub 1: 18
Sub 2: 18
Rows × Stages
Main 1: 2 × 10
Main 2: 2 × 8
Sub 1: 1 × 4
Sub 2: 1 × 4
Pipe type Copper
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net
in (mm)
11 × 38-9/16 × 9-7/16 (280 × 980 × 240)
Gross 12-11/16 × 42-7/16 × 13-5/8 (322 × 1,078 × 346)
Weight
Net
lb (kg)
29 (13)
Gross 37 (17)
Connection pipe
Size
Liquid
in (mm)
Ø1/4 (Ø6.35)
Gas Ø3/8 (Ø9.52) Ø1/2 (Ø12.7)
Method Flare
1-1. Indoor unit - (01-1) - 1. Specifications
