Item no. Part no. Part name Service part

1 9322556028 Top panel assy ♦

2 9377854001 Protective net assy ♦

3 9322327000 Thermistor holder ♦

4 9322552242 Cabinet right assy ♦

5 9384276001 Conduit cover ♦

6 9322570062 Switch cover assy ♦

7 9383720000 Drain cap assy ♦

8 9323550025 Base assy ♦

9 9322144003 Drain pipe ♦

9709683972 Main PCB (for 09 model) ♦

9709683989 Main PCB (for 12 model) ♦

9709683996 Main PCB (for 15 model) ♦

11 9900935054 Thermistor assy ♦

12 9900985011 Thermistor assy (Compressor temp.) ♦

13 9900565060 Thermistor assy (Outdoor temp.) ♦

14 9322420039 Heat sink ♦

15 9810028006 Thermistor stopper ♦

16 9317903011 Emblem ♦

17 9384273000 Fan Guard ♦

18 9322555182 Front panel assy ♦

19 9322150004 Propeller fan ♦

20 9603601003 Brushless motor ♦

21 9322553027 Motor bracket assy ♦

9317089616 Condenser total assy (for 09-12 model) ♦

9317089654 Condenser total assy (for 15 model) ♦

a — Inverter assy —

b — Hair pin cushion —

3-1. Models: AOUG09LZAS1, AOUG12LZAS1, and AOUG15LZAS1 - (02-7) - 3. Outdoor unit parts list
