En-18
SPECIFICATIONS
● Acoustic Noise Information : The maximum sound pressure level is less than 70 dB (A) for both indoor unit and outdoor
unit.
According to IEC 704-1 and ISO 3744.
MODEL
INDOOR UNIT ASY17AS ASY17RS
OUTDOOR UNIT AOY17AN AOY17RN
TYPE COOLING MODEL HEAT & COOL MODEL (REVERSE CYCLE)
POWER 1~ 220-240 V 50 Hz
COOLING
CAPACITY [kW] 4.75-4.90 4.70-4.80
POWER INPUT [kW] 1.75-1.85 1.70-1.78
CURRENT [A] 8.0-7.8 7.9-7.6
ENERGY EFFICIENCY RATIO
[kW/kW]
2.71-2.65 2.77-2.70
HEATING
CAPACITY [kW] — 5.00-5.15
POWER INPUT [kW] — 1.85-1.92
CURRENT [A] — 8.6-8.2
ENERGY EFFICIENCY RATIO
[kW/kW]
— 2.70-2.68
MAX. PRESSURE [kPa] 2,840
REFRIGERANT (R22) [g] 1,300 1,500
DIMENSIONS & WEIGHT (NET)
INDOOR UNIT
HEIGHT [mm] 285
WIDTH [mm] 900
DEPTH [mm] 172
WEIGHT [kg] 10
OUTDOOR UNIT
HEIGHT [mm] 643
WIDTH [mm] 840
DEPTH [mm] 336
WEIGHT [kg] 55 59
