2008.04.16
22
1
Top Panel Sub Assy
2
Front Panel
3
Fan Guard
4
Grip Side
5
Service Panel Assy
6
Right Panel M
7
Valve Cover Sub Assy
--
Emblem Rear
9374417025
9374094066
9374330010
9374173013
9374415038
9374599028
9374827015
9351355005
--
Protective Net
9375381011
8
Grip
9374172016
Ref.
Description
Part number
OUTDOOR UNIT
P
A
R
T
S
4
2
1
5
7
8
6
3
22
24
Table of Contents
Table of Contents
1
Air Conditioner
1
Wall Mounted Type
1
Indoor Unit
1
Specifications
2
Outline and Dimensions
4
Refrigerant System Diagram
6
Circuit Diagram
7
Indoor Pcb Circuit Diagram
9
Outdoor Pcb Circuit Diagram
10
Error Contents
13
PARTS (Indoor Unit)
15
PARTS (Outdoor Unit)
23
