This convenient guide will lead you through the start-up
process and will also offer some valuable tips.
LEFT PANEL
BOTTOM PANEL
RIGHT PANEL BACK PANEL
Controls, Connectors,
and Access Points
What’s in the Box
Check to see that all of the following items are in the box:
o LIFEBOOK notebook
o Lithium ion battery, pre-installed
o AC adapter with power cord
o Weight saver module
o Optional optical drive (pre-installed)
Depending upon your configuration, the following items may also be shipped with your notebook:
o DVD/CD-RW combo, Dual-Layer o DVD and/or CD-RW application CD
Multi-Format DVD Writer o Additional Lithium ion battery
Air VentsEject ButtonFlexible Bay USB 2.0 Ports
ExpressCard Slot
ExpressCard Eject Button
Smart
Card Slot
Anti-Theft Lock Slot
Lithium ion Battery Bay
Flexible Bay Release Latch
Emergency Tray Release
Optional Modem (RJ-11) Jack
DC Power Jack
Gigabit LAN (RJ-45) Jack
Memory Upgrade
Compartment
External Video Port USB 3.0/2.0 Port
e-SATA/USB 2.0 Combo Port
DisplayPort Connector
Battery Bay
Lock
Battery Bay Lock
Port Replicator
Connector
Dust Filter
Cover
Air Vents
(various locations)
Keyboard
Status Indicator Panel
Touchpad Pointing Device
Display Panel
Stereo Speaker
Memory Stick/SD Card Slot
Wireless Device On/Off Switch
Headphone Jack
Microphone Jack
LIFEBOOK Security/Application Panel
Power/Suspend/Resume Button
Status Indicator Panel
Stereo Speaker
Built-in Web Camera
Indicator glows blue when camera is on
Built-in Microphone
