3
Fig. 1 Indoor Unit
1 Operating Control Panel (Fig. 2)
2 MANUAL AUTO button
●
When kept on pressing the MANUAL
AUTO button for more than 10 seconds,
the forced cooling operation will start.
● The forced cooling operation is used at the
time of installation.
Only for authorized service personnel's
use.
● When the forced cooling operation starts
by any chance, press the START/STOP but-
ton to stop the operation.
3 Indicator (Fig. 3)
4 Remote Control Signal Receiver
5 OPERATION Indicator Lamp (red)
6 TIMER Indicator Lamp (green)
●
If the TIMER indicator lamp flashes when
the timer is operating, it indicates that a
fault has occurred with the timer setting
(See Page 14 Auto Restart).
7 SUPER QUIET Indicator Lamp (green)
8 COIL DRY Indicator Lamp (orange)
9 Intake Grille (Fig. 4)
0 Front Panel
A Air Filter
B Air Flow Direction Louver
C Right-Left Louver
(behind Air Flow Direction Louver)
D Drain Hose
E Air Cleaning Filter
Fig. 5 Remote Control Unit
L SLEEP button
M MASTER CONTROL button
N SET TEMP. button (
/ )
O COIL DRY button
P Signal Transmitter
Q TIMER MODE button
R TIMER SET (
/ ) button
S FAN CONTROL button
T START/STOP button
U SET button
V SWING button
W RESET button
X TEST RUN button
● This button is used when installing the
conditioner, and should not be used un-
der normal conditions, as it will cause the
air conditioner’s thermostat function to op-
erate incorrectly.
● If this button is pressed during normal op-
eration, the unit will switch to test opera-
tion mode, and the Indoor Unit’s OPERA-
TION Indicator Lamp and TIMER Indicator
Lamp will begin to flash simultaneously.
● To stop the test operation mode, press the
START/STOP button to stop the air condi-
tioner.
Y CLOCK ADJUST button
Z Remote Control Unit Display (Fig. 6)
[ Transmit Indicator
\ Clock Display
] Operating Mode Display
` Timer Mode Display
a Fan Speed Display
b Temperature SET Display
c COIL DRY Display
d SLEEP Display
e SWING Display
NAME OF PARTS
● Refer to the folded out page on the cover.
