Specifications of the ScanSnap
The following table summarizes the specifications of the ScanSnap.
Item Specification
Product Name ScanSnap S1100i
Scanning method Manual feed (Continuous Document Feeding (CDF) function
supported), simplex scanning, two selectable paper paths (U-
turn path (*1), straight path (*2))
Scanning color mode Simplex, color/gray/black and white/auto (automatic color,
gray, and B&W detection)
Optical system/image sensor Selfoc lens equal-magnification optics/color CIS × 1
Light source 3 color LED (Red/Green/Blue)
Scanning speed (A4 portrait) Automatic resolution/normal/better/best
7.5 sec/sheet
Excellent
35 sec/sheet
Scan area Refer to "Documents to Scan" (page 50)
Document thickness
Interface USB 2.0/USB 1.1 (connector: USB Mini-B type) (*3)
Input power Voltage 5 V (USB bus power)
Power consumption During operation: 2.5 W or less
During sleep mode: 1.0 W or less
Temperature/humidity
allowable ranges
Temperature During operation: 5 to 35 degrees C/41 to 95 degrees F
During standby: -20 to 60 degrees C/-4 to 140 degrees F
During storage/transportation: -20 to 60 degrees C/-4 to 140
degrees F
Humidity During operation: 20 to 80%
During standby: 8 to 95%
During storage/transportation: 8 to 95%
Outer dimensions (Width × Depth × Height) Min.: 273 × 47.5 × 34 mm/10.75 × 1.87 × 1.42 in. (when the
feed guide and output guide are closed)
Max.: 273 × 77 × 52 mm/10.75 × 3.03 × 2.05 in. (when the
feed guide and output guide are open)
Weight 350 g (approx. 0.88 lb)
Environmental specification Compliant with the International Energy Star Program, and
RoHS Directive
Related Software Scanner driver ScanSnap Manager
File management ScanSnap Organizer
Business card
management
CardMinder
Text recognition ABBYY FineReader for ScanSnap
Update management
and application
ScanSnap Online Update
ECM linkage Scan to Microsoft SharePoint
*1: When the output guide is open.
Specifications of the ScanSnap
120
