Fujitsu WPYA050LE User Manual

- 17 -
PARTS LIST
No. PARTS NAME PARTS No.
1 OUTLET GRILLE 20567790
2 FRONT PANEL ASSY. 20691630
3 RIGHT SIDE PANEL 20691780
4 LEFT SIDE PANEL ASSY. 20691800
5 TOP PANEL ASSY. 20699381
6 PROPELLER FAN 52630340
7 MOTOR 30137960
8 BRACKET,MOTOR 20681780
9 SENSOR (TEMP. OUTDOOR) 30138450
11 BOTTOM PANEL ASSY. 20705043
12 WIRING LID ASSY. 20698380
13 CONDENSER ASSY. 20692130
14 COIL,EXPANSION VALVE 30137500
15 EXPANSION VALVE 51914522
16 SENSOR (TEMP. DEFROST) 30135060
17 HEAT EXCHANGER ASSY. 20692900
18 PUMP ASSY. 20692782
20 COMPRESSOR 30137520
21 VIBRATION PROOF RUBBER 30137560
22 SENSOR
(TEMP. DISCHARGE & SUCTION)
30135050
23
24 SENSOR (TEMP. CIRCULATING WATER) 30137510
25 REACTOR 30098720
26 TERMINAL BLOCK 30112970
27 PCB (DISPLAY) 30137930
28 PCB (CONTROLLER) 30154050
29 RUBBER HOSE (FOR RELIEF VALVE) 30137730
30 RUBBER HOSE (FOR AIR PURGE VALVE) 30137740
31 HOSE BAND (FOR RELIEF VALVE) 30084480
32 HOSE BAND (FOR AIR PURGE VALVE) 68616090
33 SOUND PROOF MATERIAL 1 20694790
34 SOUND PROOF MATERIAL 2
20694800
35 SOUND PROOF MATERIAL 3 20694810
36 SOUND PROOF MATERIAL 4 20694820
37 SOUND PROOF MATERIAL 5 20695360
38 OUTDOOR THERMISTOR HOLDER 20696760
39 COIL, 4-WAY VALVE 30137490
41 RELIEF VALVE 30112670
42 AIR PURGE VALVE 30112680
43 PLUG 20742470
44 4-WAY VALVE 30104090
45 CIRCULATING WATER OUTGOING PORT ASSY. 20694710
46 CIRCULATING WATER RETURN PORT ASSY. 20694740
47 RUBBER HOSE 1 20692840
48 RUBBER HOSE 2 20692850
49 RUBBER HOSE 3 20692860
50 RUBBER HOSE 4 20692870
51 RUBBER HOSE 5 20726660
53 O RING (P3) 30015770
54 O RING (P4) 01107120
55 O RING (P6) 01107600
56 O RING (P14) 01107150
57 QUICK FASTENER 30089210
58 QUICK FASTENER 00633600
