DISASSEMBLY PROCESS
WARNING
Before servicing the unit, the power supply switch OFF,
Then, do not touch electric parts for 10 minutes due to the risk of electric shock.
１.Appearance
２.SERVICE PANEL removal
Remove the screws. Remove the SERVICE PANEL.
(3 places) by sliding downward.
Screw
Hook (4 places)
-18-
