5. VIDEO PLOTTER OPERATION
5-37
4. Roll the wheel to choose DRIVE SELECT and then push the wheel or the left
button.
5. Roll the wheel to choose appropriate drive and then push the wheel or the
left button.
6. Roll the wheel to choose data to record (one item among 4-9) and then push
the wheel or the left button. For example choose 4 WR MARK and then push
the wheel or the left button. The display then looks something like the one
below.
CARD WRITE menu
Note: The file name is composed of a single alphabet, the file type, and
seven digits, the file number. The file type is denoted as follows:
M: Mark
W: Waypoint, nav line
T: Own track
A: Target track
S: Setting data
I: Installation data
7. Use the wheel and the left button to enter file title. You may use up to seven
digits.
8. After entering the last digit of the file name the chosen item is recorded.
The message “WR CARD DATA” is shown during recording.
[WR MARK]
1 BACK
2 NAME (See note below.)
M0000000
