Furuno FCV-295 User Manual

APPENDIX 1 MENU TREE
AP-2
1
Display
A-Scope (Off, Normal, Peak)
Depth Size (Off, Small, Middle, Large)
Depth Scale (Right, Center, Off)
Zoom Marker (Off, On)
Temp Graph (Off, Narrow, Wide)
Temp Graph Color (Std, White, Red, Black, Yellow)
Pic. Adv. Dir (Left, Right, L/R)
Display Division ( , )
Color Bar (Off, On)
Hue (Custom, Std, Hue1 - Hue6)
Background (White, Light Blue, Blue, Dark Blue, Black)
Colors (8, 16, 64)
Window Color (Day, Night)
Header Info (Off, On)
Help (Off, On, Auto Close)
Alarm
Bottom (Off, On)
From (0 - 9000 ft, 0 ft)
Span (+1 - +9000 ft, +10 ft)
Fish (Normal) (Off, Defined Area, All Area)
From (0 - 9000 ft, 0 ft)
Span (+1 - +9000 ft, +10 ft)
Fish (B/L)* (Off, On)
From (0.0 - 600.0 ft, 0.0 ft)
Span (+0.1 - +600.0 ft, +1.0 ft)
Fish Level (Weak, Medium, Strong)
Temperature (Off, Inside, Outside)
From (20.0 - 110.0 °F, 65.0 °F)
Span (+0.1 - +30.0 °F, +1.0 °F)
Speed (Off, Inside, Outside)
From (0.0 - 99.0 kt, 0.0 kt)
Span (+1.0 - +50.0 kt, +1.0 kt)
Arrival Alarm (Off, Inside, Outside)
Radius (0.01 - 99.99 nm, 0.01 nm)
*: B/L mode only
2
Data
Go to WPT (Off, Destination 1 - 20)
WPT List
Data Box 1 (Speed (SOG)(Off, On), Speed (STW)(Off, On), Depth (Off, On), Range(Off, On),
Bearing (Off, On), Position (Off, On), Wind (Off, On), Heading (Off, On), Course (Off, On),
Barom Press (Off, On), Temperature (Off, On), Time to Go (Off, On), Trip Meter (Off, On),
Odometer (Off, On), XTE (Off, On), TD (Off, On), Timer (Off, On), Scroll Time (Off, On),
Battery (Off, On), Switching Cycle (2s, 4s, 6s, 8s, 10s, 15s, 20s, 30s)
Data Box 2 (Same as Data Box 1)
Bearing (True, Mag)
Nav Data (Auto, GPS, LC)
Wind Spd/Dir (True, Apparent)
Trip Source (Own, NMEA)
Temp Source (Own, NMEA)
Speed Source (Own, NMEA)
Trip Reset (Yes, No)
Odo Reset (Yes, No)
