-1.47-
1.51 Echo Area (R-type only)
You may select the size of the area in which echoes are displayed as follows:
1. Press [MENU], [0], [0], [5], [5] to show the DISPLAY menu.
DISPLAY
1. ↑
2. NAV DATA
OFF ON
3. ECHO AREA
CIRCLE
WIDE
2. Press the [3] key to select CIRCLE or WIDE referring to the illustration below.
NAV
DATA
CIRCLE WIDE
NAV
DATA
3. Press the [ENTER/SELECT] key followed by the [MENU] key.
1.52 Real Time Heading Up (R-type only)
The real time picture on the head-up mode can be displayed (default setting). If you prefer
traditional picture to the real time picture, select it as follows.
1. Press the [MENU] key to open the menu.
2. Press the [5] key twice to display the ECHO SIG menu.
3. Press the [0] key to select OFF or ON from the REALTIME HU field as appropriate.
4. Press the [ENTER/SELECT] key followed by the [MENU] key.
To Next Page
