7-5
DGPS 3D
NAV
L/L
COURSE
UP
ZOOM
OUT
ZOOM
IN
NORTH
UP
SAVE icon
S A
V E
Figure 7-9 SAVE icon appearance
on the plotter display
7. Press the [SAVE/MOB] key with a touch-
and-release action to enter a waypoint
mark at own ship position. A new waypoint
is created under the next consecutive
waypoint number and that waypoint is
added to the route.
8. Repeat step 7 as necessary. 35 waypoints
can be entered.
9. Press the [WPT/RTE] key followed by the
soft key CREATE VOYAGE BASED
ROUTE.
10.Press the soft key FINISH LOG to regis-
ter the route. The SAVE icon disappears.
7.5 Erasing Routes
1. Press the [WPT/RTE] key followed by the
soft key ROUTES to open the route menu.
2. Press ▲ or ▼ to select a route you want
to erase.
3. Press the soft key ERASE ROUTE. You
are asked if you are sure to erase the
route.
4. Press the [ENTER] key to erase the route.
