Fusion MS-AV700i User Manual

41
42
Important: If a Zone is disabled, you cannot change any of the following settings
for that Zone.
Disable Internal Amplifiers
Disable the internal amplifiers for Zones 1 and 2. For example, if external amplifiers
are used for Zones 1 and 2 the internal amplifiers can be disabled to reduce power
consumption.
To enable or disable the internal amplifiers for Zones 1 and 2:
1.PresstheMenuKey.
2.TurnandpresstheEncodertoselectSettings > Zone.
3. Select the Internal amplifier on menu item.
4.PresstheEncodertodisable()orenable()theamplifiers
5. Press any key to exit
Volume control
Zones 3 and 4 can have volume control disabled. You should disable volume control
foraZonethathasitsvolumecontrolledfromanotheramplifierorHeadunit.If
volumecontrolis:
• Enabled:turningtheEncoderwillchangelineleveloutputforthe
selected Zone only.
• Disabled:turningtheEncoderwillnotchangelineleveloutputforthe
selected Zone.
To enable or disable volume control:
a. Select the Volume Control menu item.
b. PresstheEncodertoenable()ordisable()volumecontrol.
c. Press any key to exit
Link to zone 1
Zones 1 and 2 can be linked so that any volume or sub-woofer level changes are
appliedtobothZones.Asmall“+”signisdisplayedonscreenbetweenZones1and
2 when this feature is enabled.
To link Zone 2 level to Zone 1 level:
a. Select the Link to zone 1 menu item.
b. PresstheEncodertolinkthetwoZones()orunlink()theZones.
c. Press any key to exit
Balance
To specify the balance for the selected Zone:
a. Select the Balance menu item.
b. TurntheEncodertotheleftorrighttoadjusttheBalancefortheselectedZone.
c. Press any key to exit
Volume limit
This feature is useful to limit the volume level to prevent excessive noise levels in
specific Zones.
To specify the volume limit for the selected Zone:
a. Select the Volume Limit menu item.
b. TurntheEncodertoadjustthevolumelimitfortheselectedZone.
c. Press any key to exit
Sub-woofer level
Externalamplifiersarerequiredtoaddupto4subwooferstothesystem
A single screen is used to set the sub-woofer level for all Zones.
You can access the screen:
• directlyfromanyinputsourcescreenbypressingandholdingdownthe
 Encoder,or
• fromaselectedZone’sSub level menu item, as described below.
To specify the sub-woofer level for the selected Zone:
a. Select the Sub level menu item. The Sub level screen is displayed with
the first Zone highlighted.
b. TurntheEncodertoadjustthesublevelforthehighlightedZone.
c. Ifrequired,presstheEncodertoacceptthesublevelandmove
automatically to the next Zone.
d. Press any key to exit
Name
Initially, the Zones are named Zone 1–4, but you can give each zone a name of
yourchoice(upto10charactersinlength).Theavailablecharactersincludeallthe
uppercase letters, all the lowercase letters, space and numbers. While changing the
Zonename,youcan:
• Exitwithoutsavinganychanges:presstheMenukey.
• Exitandsaveanychanges:pressandholddowntheEncoder.
