Gallagher 3E0709 B20 B35 B45 User Manual
7
English
INSTALLATION GUIDE
This energizer is designed for simple installa on and opera on. Please read these
instruc ons. Addi onal earth connec ons may be necessary in some areas.
Mount the energizer
PaddockMaster
PaddockMaster
Connect the battery
For 9V dry cell alkaline baƩ ery
Green
Red
• Connect the Green earth
lead to the earth stake.
• Connect the Red fence
lead to the Reel or fence
wire (See diagram).
Connect leads
Red
Black
BaƩ ery
For 12V Rechargeable baƩ ery
WARNING:
Remove internal ba ery
before connec ng the
12V external ba ery.
Red
Black
Green
Red
• Connect the
Green earth
lead to the
earth
• Connect the
Red fence lead
to the Reel or
fence stake.
Red
Black
Note: 12V ba ery lead set - Op onal accessory G596003/G59600
Note: Moun ng stake - Op onal accessory G87801
