6
Gallagher 3E1399 S17 S22 Portable Fence Energizer
Installa on
English
fence circuit and the supply mains equivalent to that provided by the energizer.
• Protec on from the weather shall be provided for the ancillary equipment unless this equipment is cer fi ed by the manufacturer as being
suitable for use outdoors, and is of a type with a minimum degree of protec on IPX4.
This energizer complies with interna onal safety regula ons and is manufactured to interna onal standards.
Gallagher reserves the right to make changes without no ce to any product specifi ca on to improve reliability, func on or design. E & OE.
The author thanks the Interna onal Electrotechnical Commission (IEC) for permission to reproduce Informa on from its Interna onal Publica on
60335-2-76 ed.2.0 (2002). All such extracts are copyright of IEC, Geneva, Switzerland. All rights reserved. Further informa on on the IEC is available
from www.iec.ch. IEC has no responsibility for the placement and context in which the extracts and contents are reproduced by the author, nor is
IEC in any way responsible for the other content or accuracy therein.
Save these instruc ons.
IMPORTANT BATTERY INFORMATION
Recharging the ba ery Switch the energizer off . Place in sunlight for 4 days with the
ba ery connected (RED +, Black -) OR
remove the ba ery from the
energizer and
charge the ba ery for 24 hours with a 6 V ba ery
charger at less than 1 Amp. DO NOT USE a 12V charger as this will
damage the ba ery.
Storing the energizer Switch the energizer off . Store in a well lit area so solar panel
keeps ba ery charged. Recharge ba ery before and a er
storage.
Maintenance free
ba ery
The ba ery does not require maintenance.
Ba ery replacement Use only 6 V 7 Ah sealed, valve regulated (VRLA) ba eries.
Removing the ba ery Switch the energizer off .
Disposing the energizer The ba ery must be removed from the energizer before the
energizer is disposed.
Disposing the ba ery Lead acid ba eries must be disposed of safely according to local
regula ons.
Leaking ba ery Dispose of leaking ba ery and replace with 6 v 7 Ah sealed, valve
regulated (VRLA) ba ery.
PRODUCT SPECIFICATIONS
S17 S22
Ba ery 6 V 7 Ah sealed lead acid
(2M1246)
6 V 7 Ah sealed lead acid
(2M1246)
Current draw 20 mA 30 mA
Stored energy 0.17 J 0.22 J
Output energy 0.11 J 0.16 J
Output voltage (no load) 7 kV 7.5 kV
