Gardena Powermax 42 e User Manual

3. To secure, position loop over the hook and pull
the cable back through the slot (L3).
4. Connect plug to mains and switch on.
The switchbox is provided with a lock-off
button (L4) to prevent accidental starting.
5. Press and hold the lock-off button (L4) on the
switchbox, then squeeze one of the Start/Stop
levers towards the upper handle (L5).
6. Continue to squeeze the start/stop lever
towards the upper handle and release the
lock-off button (L6).
• NOTE - There are two start/stop levers
fitted. Either one can be used for starting
the lawnmower.
• IMPORTANT - Do not use the start/stop
levers intermittently
To Stop your Lawnmower
1. Release the pressure on the Start/Stop lever.
PAGE 7
M
grassbox
empty
grassbox
full
N1
N2
N3
N4
Using as a mulcher
1. Your lawnmower is supplied with a mulching
plug. (N1)
2. Stop your lawnmower as described in Starting
and Stopping.
3. Lift safety flap and insert the mulching plug into
rear discharge chute. (N2) ensuring it is
securely fitted. (N3)
4. The mulching plug prevents grass from being
collected by blocking the collection chute on
the underside of the deck. (N4)
Grassbox Full Window
• As the grassbox fills up, grass will be visible
through the window (M).
• When the window/grassbox is full it is time to
empty the grassbox.
Mulching Plug
L3
L6
L4
L5
Starting and Stopping cont’

Gardena Powermax 42 e Specifications

General

Power source	AC
Cordless	No
Type	Push lawn mower
Cutting width	420 mm
Cutting system	Rotary blades
Recommended lawn area	800 m²
Maximum cutting height	60 mm
Minimum cutting height	20 mm
Grass collecting volume	50 L

Weight and Dimensions

Weight	13900 g
