Problem Possible Cause Remedy
Trimmer is not cutting
cleanly or not cutting at all
Plastic blade is broken off. v
Replace the plastic blade.
Trimmer vibrates severely Plastic blade is excessively
worn and creates an unbalance.
v
Replace the plastic blade.
Blade carrier is worn. v
Replace the blade carrier.
Trimmer can no longer be
stopped
Start lever is stuck. v
Remove the battery and
loosen the start lever.
Trimmer does not start
or stops.
LED
«
is flashing green
[ Fig. O4 ]
Battery is empty. v
Charge the battery.
Trimmer does not start
or stops.
Error-LED
ç
is illuminated
red [ Fig. O4 ]
Battery temperature is outside
the permissible temperature
range.
v
Wait until the battery tem-
perature is between
0 °C – + 45 °C again.
There are drops of water or
moisture between the battery
contacts on the trimmer.
v
Remove the water drops /
moisture with a dry cloth.
Engine is blocked. v
Remove the obstacle.
Start again.
Trimmer does not start
or stops.
Error-LED
ç
is flashing red
[ Fig. O4 ]
Product is defective. v
Contact the GARDENA
Service.
Trimmer does not start
or stops.
Error-LED
ç
is not
illuminated [ Fig. O4 ]
Battery is not put completely
into the battery holder.
v
Put the battery completely
into the battery holder until
it audibly engages.
Battery is defective. v
Replace the battery.
Product is defective. v
Contact the GARDENA
Service.
Charging is not possible.
Battery charge indicator
å
is continuously illuminated
[ Fig. O3 ]
The battery is not connected
(correctly).
v
Connect the battery to
charger correctly.
Battery contacts are dirty. v
Clean the battery contacts
(e. g. by connecting and
disconnecting the battery
several times. Replace the
battery if necessary.
Battery temperature is outside
the permissible charging
temperature range.
v
Wait until the battery
tem perature is between
0 °C – + 45 °C again.
Battery is defective. v
Replace the battery.
Battery charge indicator
å
is not illuminated [ Fig. O3 ]
Mains plug of the charger is
not (correctly) plugged in.
v
Insert the mains plug into the
mains socket (completely).
Socket outlet, mains cable or
charger is defective.
v
Check the mains voltage.
Let the charger be checked
if necessary by an authorised
specialist dealer or the
GARDENA Service.
NOTE: For any other malfunctions please contact the GARDENA service depart-
ment. Repairs must only be done by GARDENA service departments or specia-
list dealers approved by GARDENA.
7. TECHNICAL DATA
Battery Trimmer
Unit Value (Art. 14702)
Rated current A 3.0
Rated voltage V (DC) 18
Cutting width cm 23
Rpm of blade carrier R/min. 9500
Weight (without Battery) g 1630
Sound pressure level L
pA
1)
Uncertainty k
pA
dB (A)
77
3.0
Sound power level L
WA
2)
:
measured/guaranteed
Uncertainty k
WA
dB (A)
85 / 86
1.5
Hand/arm vibration a
vhw
1)
Uncertainty k
vhw
m/s
2
3.2
1.5
Measuring process complying with:
1)
EN 50636-2-91
2)
RL 2000/14/EC / S.I. 2001 No.1701
NOTE: The stated vibration emission value has been measured according to
astandardised test procedure and can be used for comparison of one electric
power tool with another. It can also be used for preliminary evaluation of expo-
sure. The vibration emission value can vary during actual use of the electric power tool.
System Battery
Unit Value (Art. 14902)
PBA 18V 2,0Ah W-B
Battery voltage V (DC) 18
Battery capacity Ah 2,0
Number of cells (Li-Ion) 5
Appropriate POWER FOR ALL system Battery Chargers: AL 1810 CV / AL 1815 CV / AL18-20 /
AL 1830 CV / AL 1880 CV.
Battery Charger
AL 1810 CV P4A
Unit Value (Art. 14900)
Mains voltage V (AC) 220 – 240
Mains frequency Hz 50 – 60
Rated power W 26
Battery charging voltage V (DC) 18
Max. battery charging
current
mA 1000
Battery charging time 80 % /
97 – 100 % (approx.)
PBA 18V 2,0Ah W-B
PBA 18V 2,5Ah W-B
PBA 18V 4,0Ah W-C
min.
min.
min.
96 / 124
120 / 154
192 / 244
Permitted charging
temperature range
°C 0 – 45
Weight according to
EPTA-Procedure 01:2014
kg 0,17
Protection class
/ II
Appropriate POWER FOR ALL system Batteries: PBA 18V.
8. ACCESSORIES
GARDENA Spare Blades
RotorCut for Turbotrimmer
As replacement for consumed plastic blades. Art. 5368
GARDENA Replacement
blade carrier
Available via the GARDENA Service.
GARDENA System Battery
PBA 18V/45 P4A
PBA 18V/72 P4A
Battery for additional duration or for replacement.
Art. 14903
Art. 14905
GARDENA Battery Quick
Charger AL 1830 CV P4A
Charger for fast charging the POWER FOR ALL
System Batteries PBA 18V..W-..
Art. 14901
9. SERVICE / WARRANTY
Service:
Please contact the address on the enclosed warranty card.
Warranty statement:
The warranty is only granted according to the warranty conditions printed
on the enclosed warranty card.
Consumables:
The plastic blade and the blade carrier are consumables and are not
included in the warranty.
EN
12
