12
EN
5. Remove the battery from the Control Unit / Radio Receiver.
6. Lock the box lid (see 3. Assembly
“Lock the box lid”
).
The product must not be added to normal household waste. It
must be disposed of in line with local environmental regulations.
v Important: Make sure that the unit is disposed of via your
municipal recycling collection centre.
6. Trouble-Shooting
Fault Possible Cause Remedy
Watering Valve does not Watering Controller / v Connect Watering
open, no water flow Controller not connected Controller / Controller /
correctly to Watering Valve. correctly to Watering Valve.
No water supply. v Turn on water supply.
Watering Valve does not Watering Valve installed in v Turn Watering Valve in
close, constant flow of opposite direction to flow the box (observe the
water direction. direction of the water flow).
Selector lever
K
set to v Set selector lever
K
to
“ON” position. “AUTO / OFF”.
A
In the event of other faults please contact GARDENA Service.
Repairs should only be carried out by GARDENA service centres or dealers
authorised by GARDENA.
7. Accessories
GARDENA Soil Moisture Sensor Art. No. 1188
GARDENA Rain Sensor electronic Art. No. 1189
GARDENA Extension Cable for
Soil Moisture Sensor and
Rain Sensor electronic Art. No. 1186
GARDENA Connection Cable Art. No. 1280
GARDENA Connecting Clips Art. No. 1282
GARDENA Central Filter Art. No. 1506 / 1510
8. Technical Data
Irrigation Valve Operating pressure 0.5 to 12 bar
Flow medium clean fresh water
Max. water temperature 40 °C
Control
Filter
Disposal:
(in accordance with
Directive 2012/19/EU)
