Page 1-2 GTX 320/320A Installation Manual
Rev M 190-00133-01
1.3.2 Physical Characteristics-GTX 320
Table 1-2 GTX 320 Physical Characteristics
Characteristic Specification
Bezel Height 1.63 inches (41 mm)
Bezel Width 6.25 inches (159 mm)
Rack Height (Dimple to Dimple) 1.71 inches (43 mm)
Rack Width 6.30 inches (160 mm)
Depth Behind Panel with Connectors (measured from face
of aircraft panel to rear of connector backshells)
8.78 inches (223 mm)
Weight (Unit Only) 1.7 lbs. (0.8 kg)
Weight (Installed with rack and connectors) 2.3 lbs. (1.1 kg)
1.3.3 Physical Characteristics-GTX 320A
Table 1-3 GTX 320A Physical Characteristics
Characteristic Specification
Bezel Height 1.63 inches (41 mm)
Bezel Width 6.25 inches (159 mm)
Rack Height (Dimple to Dimple) 1.71 inches (43 mm)
Rack Width 6.30 inches (160 mm)
Depth Behind Panel with Connectors (measured from face
of aircraft panel to rear of connector backshells)
8.78 inches (223 mm)
Weight (Unit Only) 2.3 lbs. (1.1 kg)
Weight (Installed with rack and connectors) 2.9 lbs. (1.3 kg)
1.4 Equipment Available
1.4.1 Available Configurations
Table 1-4 Available Configurations
Item Garmin P/N
Garmin GTX 320 Transponder 010-00135-00
Garmin GTX 320A Transponder 010-00247-00
Garmin GTX 320 Transponder includes Garmin installation kit,
P/N 010-10161-00
010-00135-03
Garmin GTX 320A Transponder includes Garmin installation kit,
P/N 010-10161-01
010-00247-02
