2.3 Lift the hinge (and the shim glued to it) straight
up to free the hinge pin from the socket in
the top of the door and set it aside, along with
its screws.
19
Installation Instructions
1.1 Unplug the refrigerator from its electrical
outlet.
BEFORE YOU START
1
2.1 Tape the door shut with masking tape.
REMOVE THE FREEZER DOOR
2
REMOVE THE FREEZER DOOR
(CONT.)
2
Top Hinge
1.2 Empty all door shelves, including the dairy
compartment.
CAUTION: Do not let either door drop to the
floor. To do so could damage the door stop.
2.2 With a 5/16″ hex-head socket driver, remove the
screws that hold the top hinge to the cabinet.
2.6 Using a Torxdriver, transfer the 2 screws from
the opposite side of the cabinet to the screw
holes vacated by the top hinge removal.
2.5 Set the door on a non-scratching surface with
the outside up.
2.4 Remove the tape and tilt the door away from the
cabinet. Lift it off the center hinge pin.
To Next Page
