15
Trim kits and decorator panels.
Read these instructions completely and carefully.
Before You Begin
Some models are equipped with trim kits that allow you to install door panels.
Panels less than 6.3 mm thick
When installing wood panels less than 6.3 mm thick, you need to create a filler panel, such as cardboard, that will
fit between the face of the door and the wood panel. If you are installing the pre-cut decorator panels, pre-cut filler
panels are included in the kit. The combined thickness of the decorator or wood panel and the filler panel should
be 8.7 mm with the panel itself being no larger than 6.3 mm.
For panel required models
Panels 6.3 mm thick or less
6.3 mm max
The handle and the top and bottom trim stand in front of the surface of the door, which requires that the filler
be smaller in length and width than the panel. Use the guidelines below and tape the filler onto the back of
the panel.
Left Fresh Food Door
Freezer Door
Filler
63.5 mm
19.1 mm
19.1 mm
Panel
Filler
63.5 mm
19.1 mm
Panel
Right Fresh Food Door
Filler
63.5 mm
19.1 mm
19.1 mm
Panel
