GE CCGS995 User Manual

26 29-6181
Oven Door
CARE AND CLEANING: Oven Door
Lift-Off Oven Door
The door is very heavy. Be careful when removing and lifting the door. Do not lift door by the handle.
To Remove the Door:
1. Fullyopenthedoor.
2. Pullthehingelocksupandawayfromtherange
frame to the unlocked position.
3. Firmly grasp both sides of the door near the top.
4. Close door until the top of the door is approximately
6”(15.2cm)fromtherangeframe.
5. Lift door up and away from the range until both hinge
arms are clear of the slots in the range frame.
To Replace the Door:
1. Firmlygraspbothsidesofthedoornearthetop.
2. With the door at the same angle as the removal
position, rest the notch on the underside of the left
hinge arm on the bottom edge of the left hinge slot.
The notch in the hinge arm must be fully seated into
the bottom of the slot. Repeat for the right side.
3. Fully open the door. If the door will not fully open, the
notches in the bottoms of the hinge arms have not
seated correctly in the bottom edge of the slot. Lift the
door off the range and repeat previous step.
4. Pushthehingelockstowardtherangecavityand
down to the locked position.
5. Close the oven door.
Removal positionPullhingelocksuptounlock
Pushhingelocksdownto
lock
Rest notch on bottom edge
of hinge slot
Notch
Bottom
edge of
slot
Hinge arm
Lift-Off Upper Oven Door
The door is very heavy. Be careful when removing and lifting the door. Do not lift door by the handle.
To Remove the Door:
1. Fullyopenthedoor.
2. Lift up on the hinge lock toward the oven frame until
they stop.
3. Closethedoorto45degrees(youwillfeelthedoor
stop).Thehingelockwillcontacttheovenframe.
4. On both sides of the door, press down on the release
buttons on each hinge.
5. Lift door up until it is clear of the hinge.
6. Pullonhingearmsslightlytorelievepressureonthe
locking tabs.
7. Pushthehingelocksdownontothehinge.
8. Pushthehingesintowardtheunitsotheyareclosed.
To Replace the Door:
1. Pullthehingesdownawayfromtheovenframeto
the fully open position.
2. Lift up on the hinge locks toward the oven frame until
they stop.
3. The hinges will release to the 45-degree position. The
hinge locks will contact the oven frame.
4. Slide the door back onto the hinges. Make sure the
buttons pop back out.
5. Fully open the door.
6. Pushthehingelocksdownontothehinge.
7. Close the oven door.
Oven
frame
Door
frame
Release
buttons
Pulldown
Pushin
