These instructions are for changing the hinges from
If you need to change the hinges from the left side to
the right side to the left side.
the right side, follow these same instructions (merely
reverse all references to the left and right).
Tools Needed
Standard #2 Phillips screwdriver
Tape-tipped putty knife
Needle-nosed pliers
Dryer Door
1. Open the door and remove the filler plugs from
the side of the opening without hinges. Use a
tape-
tipped putty knife to pry plugs loose and then gently
remove plugs with a pair of needle-nosed pliers.
2. With the door
completely open,
remove the bottom
screw from each hinge
on the dryer face.
3. Insert these screws
about half way into
the top holes, for
K
\
*W
“
~–
)1
II
i
---
‘L
&-
)
each hinge, on the
opposite side (where
filler plugs were removed). Apply
firm pressure to get screw started in
untapped holes.
4. Loosen the top screw from
each hinge on the dryer face
half way.
m
I@
Qo
5. With one hand holding the top
–
of the door and the other hand
holding the bottom, remove the
door from the dryer by lifting it up and out.
h
+y
~?>
6. Rotate the door 180°. Insert it
~
1
/
II
on the opposite side of the
~
. .
.
opening by moving the door
in and down until the top
/
hinge and the bottom hinge
s
are resting on the top screws
!
\ Uli
inserted in step 3.
7. Remove the remaining
screws from the side of
the opening from which
the door was removed.
With these screws,
1’
@
Q-
-w
secure each hinge at
the bottom.
,0
@@
8. Tighten the two top
screws of each hinge.
9. Reinsert the plastic plugs on
the side from which the door was removed.
11
