HOW TO CHANGE COLOR PANELS
If you are redecorating, you can change your dishwasher’s front panels
to match or blend with your new colors by flipping them over. You may
also paint a panel with a color of your own choice.
How to Change the Door Panel:
1. Take out trim screws on either side of the
dishwasher door. Remove the side trim.
2. Slide the door panel out.
(Careful—edges may be sharp.)
3. Turn the door panel around and put the color you
want in front.
4. Replace the door panel, side trim and screws.
NOTE: Do not operate
dishwasher while changing
panels or when lower access
panel is removed.
How to Change the Bottom Panel:
1. Remove the bottom panel attachment screws.
2. On models without top mounting screws, remove
the entire access assembly by rotating the bottom
out and lifting it up and over the retaining tabs.
3. On models with top mounting screws, remove
the screws.
4. Take out the top trim screws and remove the
top trim.
5. Slide the color panel(s) up and out and put the
color you want in front.
6. Replace the top trim and screws.
7. Replace the entire access assembly by reversing
the steps.
Bottom Panel Attachment Screws
Top
Trim
Top
Mounting
Screw
Retaining
Tab
or
Adding 1/4″ Wood Inserts
Color insert panels for both the door and the lower panel can be replaced by
1/4″ thick wood inserts to match your kitchen cabinets. Get them from your
nearest cabinet or lumber dealer.
Dimensions for 1/4″ wood inserts:
Door Panel: 19
1
⁄8″ H x 23
9
⁄16″ W.
Lower Panel: 3
11
⁄16″ H x 23
9
⁄16″ W.
