– 27 –
Dryer Components
Tub Assembly 460 485 and 490 Models
Internal Drain
Hose and Clamp
Motor
Motor and
Transmission
Belt Pulleys
Platform/
Transmission
with Tub Seal
Main
Harness
Drain
Pump Seal
Drain Pump
Hub
Nut and
Belleville
Washer
Belt
Mode Shifter
Clutch
Motor Shield
Mode Shifter
Belt Protector
Tub Cover
Auger
Rod and Spring
Assembly
Agitator
Base And
Bolt
Fabric Softener
Dispenser
Harness Bracket
