– 37 –
# PART NUM. DESCRIPTION QTY
1 WB36T10274 TRIM CONTROL (PROFILE) 1
2 WB36T10250 END CAP/ALMOND 1
2 WB36T10249 END CAP/ALMOND 1
3 WB02T10022 HEAT SHIELD 1
7 WB02T10052 BALLAST MOUNT 1
15 WB24T10015 INF CNTRL SWITCH (DUAL) 2
15 WB34T10020 CONTROL COVER 1
16 WB27T10077 OVEN CNTL (ERC) 1
19 WB24T10032 INFINITE CONTROL SWITCH 1
19 WB24T10012 INFINITE WARMER SWITCH 1
20 WB02T10046 CRYSTAL RETAINER 4
28 WB02T10047 CRYSTAL MOUNT 4
29 WB03T10077 KNOB PROFILE SU 4
32 WB26T10007 FAN MOTOR 1
33 WB25T10008 INDICATOR LIGHT ASM (RT) 1
33 WB25T10007 INDICATOR LIGHT ASM (LT) 1
35 WB02X4666 FLUORESCENT LIGHT BULB 1
38 WB36T10252 LAMP HOLDER 1
43 WB02T10018 FAN BLADE 1
45 WB34K5140 PROBE COVER 1
45 WB20X5064 THERMISTOR PROBE 1
56 WB30K5033 HALIANT ELEMENT - 1500W 1
57 WB30T10036 HALIANT ELEMENT 1
58 WB30T10035 HALIANT ELEMENT 9" 1
60 WB09T10002 RADIANT ELEMENT SPRING 8
66 WB34T10018 ENCLOSURE RANGE TOP 1
70 WB02T10045 FOAM STRIP 1
91 WB10T10002 MAINTOP HINGE 2
94 WB02T10038 RADIANT CHASSIS BRACE 2
101 WB35T10018 DOOR INSULATION 2
101 WB35T10016 DOOR INSULATION 1
101 WB35T10019 DOOR INSULATION 2
105 WB07X7352 HANDLE TRIM ALMOND 2
108 WB01X5904 SCR 8-18 BA POR 3/4 SN 2
111 WB04T10001 OVEN GASKET 1
112 WB55T10050 DOOR LINER ASSEMBLY 1
113 WB56T10027 INSLN RETAINER 1
121 WB56T10041 PANEL ASM (BONDED) 1
121 WB56T10039 GLASS DOOR OUTER 1
131 WB01T10022 DOOR BUMPER 2
131 WB04T10002 SEAL WINDOW PACK 1
133 WB01T10023 RADIANT HEATER PAD 4
133 WB01T10021 MAIN TOP BUMPER 2
133 WB01T10026 DOOR PAD 2
134 WB07T10120 DOOR VENT TRIM 1
136 WB15X5225 DOOR HANDLE ALMOND 1
140 WB56T10020 DOOR FRAME 2
142 WB06K0007 STARTER 1
151 WB15T10018 MOTORIZED LATCH ASM 1
178 WB35T10020 DOOR LOCK INSULATION 1
201 WB53T10004 OVEN BODY WELD ASM 1
202 WB63T10054 FRONT FRAME 1
203 WB63T10047 MAIN BACK 1
204 WB55T10046 STORAGE DRAWER LINING 1
211 WB02T10028 SIDE INSUL RETAINER 2
217 WB34T10012 BACK COVER 1
219 WB34T10011 RECEPTICLE COVER 1
221 WB63T10050 BODY SIDE ALMOND 2
222 WB56T10015 FRONT PANEL STOR/ALMD 1
227 WB02T10029 TOP INSUL RETAINER 1
229 WB35T10021 CONVX INSULATION 1
229 WB35T10017 VENT TUBE INSULATION 1
231 WB35T10012 OVEN TOP/SIDE INSULATION 1
232 WB35T10023 OVEN BLACK/BTM INSUL 1
233 WB35T10022 HIDDEN BACK INSULATION 1
233 WB49T10005 REFLECTOR PLATE 1
# PART NUM. DESCRIPTION QTY
241 WB48T10015 OVEN RACK 1
241 WB48T10019 RACK OFFSET DOWN 1
241 WB48T10015 OVEN RACK 1
241 WB48T10018 LARGE ROASTING RACK 1
242 WB48T10012 DRAWER GUIDE 2
246 WB48T10017 BROILER PAN GRID LG 1
247 WB48T10016 BROILER PAN LARGE 1
248 WB23T10002 SENSOR ASM 1
251 WB44T10015 UNIT ASM (HB) 1
252 WB44T10012 UNIT BROIL ASM DELUX 1
252 WB10T10005 HINGE RECEIVER 2
255 WB07T10109 LATCH TRIM 1
255 WB17T10003 MAIN TERMINAL BLOCK 1
256 WB02X10521 FOOT LEVELING 4
258 WB02T10027 OVEN LIGHT GASKET 1
258 WB02T10037 OVEN LIGHT CUP 1
266 WB39T10001 BASE RIVET ASM 1
269 WB17T10002 TERMINAL BOX 1
272 WB02T10034 SIDE PANEL SUPPORT 4
277 WB24X5316 OVEN LIGHT SWITCH 1
279 WB08T10004 PUSH-IN RECEPTICLE 1
282 WB38T10013 RADIANT VENT TUBE 1
282 WB38T10012 VENT TUBE ASM
291 WB08X5102 BALLAST 1
292 WB48T10013 FRONT DRAWER SUPPORT 2
292 WB02T10031 REAR DRAWER SUPPORT 2
298 WB44T10001 CONVX ELEMENT 1
302 WB02X7694 LIGHT LENS BAIL 1
303 WB36X0389 OV LAMP LENS 1
312 WB01X0119 CONTOURED WASHER 2
459 WB01K5062 SCREW BRT. NI. 4
461 WZ05X0158 SCREW 8-32X3/8 GRD SCR 1
472 WB49T10007 SIDE REFLECTOR 1
489 WB49T10006 PAN REFLECTOR 1
514 WB34T10019 CONVECTION FAN COVER 1
534 WB02T10044 CONVX FAN MOTOR BRKT 1
549 WB08T10005 JACK RECEPTACLE 1
712 WB02X8309 PROBE COVER 1
919 WB02T10035 SPACER 2
929 WB02T10026 MAIN TOP STRIKE 2
998 WB02T10053 ANTI TIP BRACKET ASM 1
1024 WX12X1510 BULB OVEN LIGHT 1
WB64X0093 GLASS CLEANER 1
WB06K5036 RAZOR BLADE SCRAPER 1
49-8443 COOKBOOK 1
31-10306 INSTRUCTION SHEET 1
MODEL JB960AB1AA
EXPLODED PARTS BREAKDOWN
The parts numbers listed above are intended
only as a reference to aid you in a better
understanding of the exploded parts views
shown on previous pages. At the time of this
publication the numbers shown above were
still preliminary and should not be used to
order parts. For model specific information,
ALWAYS consult the microfiche.
*
