GE JK3800SHSS User Manual

24
49-80737
SHOCK OR BURN HAZARD: Before replacing oven light bulb, disconnect the electrical
power to the oven at the main fuse or circuit breaker panel. Failure to do so may result in
electric shock or burn.
WARNING
BURN HAZARD: The glass cover and bulb should be removed when cool. Touching hot
glass with bare hands or a damp cloth can cause burns.
CAUTION
Lower Oven Light Replacement
1. Disconnect power at the main fuse or circuit breaker
panel.
2. Remove oven racks.
3. Slide a flat blade screwdriver between the housing
and the glass light cover.
4. Support the glass light cover with two fingers to
prevent the cover from falling to the bottom of the
oven. Be careful not to chip the oven coating.
5. Gently twist the screwdriver blade to loosen the
glass light cover.
6. Remove the glass light cover.
7. Remove the bulb by firmly grasping and sliding the
bulb straight out until the two prongs have cleared
the ceramic holder.
8. Do not touch the glass of the new replacement bulb
with your fingers. It will cause the bulb to fail when it
lights. Grasp the replacement bulb with a clean towel
or facial tissue with the prongs facing down. Align
the two prongs in the ceramic holder, pressing gently
until the bulb is securely in the ceramic socket.
 6OLGHWKHSURWHFWLYHOHQVLQWRWKHKROGHUDQGSXVK
until the clips snap into the housing.
10. Reconnect power.
Lower Oven Maintenance
CARE AND CLEANING: Lower Oven Maintenance
Lift-Off Lower Oven Door
The door is very heavy. Be careful when removing and lifting the door.
Do not lift the door by the handle.
To remove the door:
1. Fully open the door.
2. Pull the hinge locks down toward the door frame, to
the unlocked position. A tool, such as a small flat-
blade screwdriver, may be required.
3. Firmly grasp both sides of the door at the top.
4. Close door to the door removal position. The door
should be open approximately 3" with no obstruction
above the door.
5. Lift door up and out until both hinge arms are clear of
the slots.
To replace the door:
1. Firmly grasp both sides of the door at the top.
2. Starting on the left side, with the door at the same
angle as the removal position, seat the indentation of
the hinge arm into the bottom edge of the hinge slot.
The notch in the hinge arm must be fully seated into
the bottom of the slot. Repeat for right side.
3. Fully open the door. If the door will not fully open, the
indentation is not seated correctly in the bottom edge
of the slot.
4. Push the hinge locks up against the front frame of the
oven cavity, to the locked position.
5. Close the oven door.
Removal position
Hinge lock
Slot
Pull hinge locks down to unlock
Push hinge locks up to lock
Hinge
lock
Hinge
arm
Indentation
Bottom
edge of
slot
Hinge arm

GE JK3800SHSS Specifications

General

Style	double; built-in
Color	stainless steel
Total Capacity	6 cu. ft.
Power Levels	10
Special Features	audible preheat signal; certified sabbath mode; c° or f° programmable; control lock capability; defrost mode; delay start; delay clean option; electronic clock & kitchen timer; 8-pass broil element; 10-pass bake element
Temperature Probe	no
Microwave	yes
Convection	no
Racks	3 self-clean heavy-duty oven racks (lower); 6 embossed rack positions (lower)
Control Type	digital and knobs
Interior Light	yes
Remote Control	no
Wi-Fi	no
Kitchen Timer	yes
Power Consumption	1000; 3, 400
Electrical Requirements	120v; 60hz
Voltage	240/208 volts
Current	30

Weight and Dimensions

Depth	26 23/32 inch
Height	43 7/8 inch
Width	26 23/32"
Net Weight	172 lbs.
