GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
Chapter 2 Site preparations 2 - 1
Chapter 2
Site preparations
Section 2-1
Overview
2-1-1 Purpose of this chapter
This chapter provides the information required to plan and prepare for the setup of a LOGIQ E9.
Included are descriptions of the facility and electrical needs to be met by the purchaser of the LOGIQ E9.
Section 2-2
General console requirements
2-2-1 Console environmental requirements
2-2-1-1 If the LOGIQ E9 is very cold or hot
When unpacking the device, allow the temperature of the device to stabilize before powering up. The
following table describes guidelines for reaching operational temperatures from storage or transport
temperatures. See: Table 2-1’
2-2-1-2 Environmental specifications
Table 2-1 LOGIQ E9 Acclimate Time
o
C
60 55 50 45 40 35 30 25 20 15 10 5 0 -5 -10 -15 -20 -25 -30 -35 -40
o
F
140 131 122 113 104 95 86 77 68 59 50 41 32 23 14 5 -4 -13 -22 -31 -40
Hrs 864200000002468101214161820
Table 2-2 Environmental Specifications for LOGIQ E9 Scanners
Operational Storage Transport (< 16 hrs.)
Temperature
10º - 35º C
(50º - 96º F)
-10º - 50º C
(-14º - 122º F)
-10º - 50º C
(-14º - 122º F)
Humidity
30% - 80%
non-condensing
30% - 80%
non-condensing
30% - 80%
non-condensing
Pressure 70 - 106 kPa 70 - 106 kPa 70 - 106 kPa
Heat Dissipation
4712 Btu/hour “ “
