5
6
3
4
2
1
INSTALLING THE
CHARCOAL FILTER
C6.
MOUNT THE MICROWAVE
OVEN
(continued)
C5.
Install the charcoal filter. When properly installed,
the wire mesh of the filter should be visible from
the front.
Replace the grille and the screws.
Close the door.
22
Charcoal
Filter
Insert mesh-side up
Remove screws on top front of grille using a
#2 Phillips screwdriver.
Open the door.
Remove the grille.
Installation Instructions
8
7
6
Tighten the remaining three screws to the top of
the microwave oven. (While tightening screws,
hold the microwave oven in place against the
wall and the top cabinet.)
Insert 3 self-aligning screws
through outer top cabinet
holes. Turn two full turns on
each screw.
Tighten right
center screw
completely.
Install grease filters. See the Owner’s Manual
packed with the microwave.
5
To Next Page
