gefran 4T72 User Manual

• Information display
I F
Software version
Display the type of CPU board
(thermocouples/linear)
Information display
Type Type 4 DIGIT 3 DIGIT + sign 2 DIGIT + sign
PROBE
without dec. point with dec. point without dec. point with dec. point without dec. point with dec. point
Probe: TC
0TCJ°C 0/1000 0.0/999.9 0/999 0.0/99.9 0/99 not available
1TCJ°F 32/1832 32.0/999.9 32/999 32.0/99.9 32/99 not available
2TCK°C 0/1300 0.0/999.9 0/999 0.0/99.9 0/99 not available
3TCK°F 32/2372 32.0/999.9 32/999 32.0/99.9 32/99 not available
4TCR°C 0/1750 0.0/999.9 0/999 0.0/99.9 0/99 not available
5TCR°F 32/3182 32.0/999.9 32/999 32.0/99.9 32/99 not available
6TCS°C 0/1750 0.0/999.9 0/999 0.0/99.9 0/99 not available
7TCS°F 32/3182 32.0/999.9 32/999 32.0/99.9 32/99 not available
8TCT°C -200/400 -199.9/400.0 -200/400 -99.9/99.9 -99/99 not available
9TCT°F -328/752 -199.9/752.0 -328/752 -99.9/99.9 -99/99 not available
10 TC B °C 44/1800 44.0/999.9 not available not available not available not available
11 TC B °F 111/3272 111.0/999.9 not available not available not available not available
12 TC E °C -100/750 -100.0/750.0 -100/750 not available not available not available
13 TC E °F -148/1382 -148.0/999.9 -148/999 not available not available not available
14 TC N °C 0/1300 0.0/999.9 0/999 not available non dsip. not available
15 TC N °F 32/2372 32.0/999.9 32/999 not available not available not available
16 TC L °C 0/600 0.0/600.0 0/600 0.0/99.9 0/99 not available
17 TC L °F 32/1112 32.0/999.9 32/999 32.0/99.9 32/99 not available
18 TC U °C -200/400 -199.9/400.0 -200/400 -99.9/99.9 -99/99 not available
19 TC U °F -328/752 -199.9/752.0 -328/752 -99.9/99.9 -99/99 not available
20 TC G °C 0/2300 0.0/999.9 0/999 not available not available not available
21 TC G °F 32/4172 32.0/999.9 32/999 not available not available not available
22 TC D °C 0/2300 0.0/999.9 0/999 not available not available not available
23 TC D °F 32/4172 32.0/999.9 32/999 not available not available not available
24 TC C °C 0/2300 0.0/999.9 0/999 not available not available not available
25 TC C °F 32/4172 32.0/999.9 32/999 not available not available not available
26 TC °C Custom Custom Custom Custom Custom not available
27 TC °F Custom Custom Custom Custom Custom not available
Probe: RTD
28 PT100 °C -200/600 -199.9/600.0 -200/600 -99.9/99.9 -99/99 not available
29 PT100 °F -328/1112 -199.9/999.9 -328/999 -99.9/99.9 -99/99 not available
30 JPT100 °C -200/600 -199.9/600.0 -200/600 -99.9/99.9 -99/99 not available
31 JPT100 °F -328/1112 -199.9/999.9 -328/999 -99.9/99.9 -99/99 not available
Probe: PTC - NTC
32 PTC °C -55/120 -55.0/120.0 -55/120 -55.0/99.9 -55/99 not available
33 PTC °F -67/248 -67.0/248.0 -67/248 -67.0/99.9 -67/99 not available
34 NTC °C -10/70 -10.0/70.0 -10/70 -10.0/70.0 -10/70 not available
35 NTC °F 14/158 14.0/158.0 14/158 14.0/99.9 14/99 not available
Probe: Voltage + Current
36 0...60mV -1999/9999 -199.9/999.9 -999/999 -99.9/99.9 -99/99 -9.9/9.9
37 0...60mV custom linear custom linear custom linear custom linear custom linear custom linear
38 12...60mV -1999/9999 -199.9/999.9 -999/999 -99.9/99.9 -99/99 -9.9/9.9
39 12...60mV custom linear custom linear custom linear custom linear custom linear custom linear
40 0...20mA -1999/9999 -199.9/999.9 -999/999 -99.9/99.9 -99/99 -9.9/9.9
41 0...20mA custom linear custom linear custom linear custom linear custom linear custom linear
42 4...20mA -1999/9999 -199.9/999.9 -999/999 -99.9/99.9 -99/99 -9.9/9.9
43 4...20mA custom linear custom linear custom linear custom linear custom linear custom linear
44 0...10V -1999/9999 -199.9/999.9 -999/999 -99.9/99.9 -99/99 -9.9/9.9
45 0...10V custom linear custom linear custom linear custom linear custom linear custom linear
46 2...10V -1999/9999 -199.9/999.9 -999/999 -99.9/99.9 -99/99 -9.9/9.9
47 2...10V custom linear custom linear custom linear custom linear custom linear custom linear
48 0...5V -1999/9999 -199.9/999.9 -999/999 -99.9/99.9 -99/99
49 0...5V custom linear custom linear custom linear custom linear custom linear custom linear
50 1...5V -1999/9999 -199.9/999.9 -999/999 -99.9/99.9 -99/99 -9.9/9.9
51 1...5V custom linear custom linear custom linear custom linear custom linear custom linear
52 0...1V -1999/9999 -199.9/999.9 -999/999 -99.9/99.9 -99/99 -9.9/9.9
53 0...1V custom linear custom linear custom linear custom linear custom linear custom linear
54 200mV...1V -1999/9999 -199.9/999.9 -999/999 -99.9/99.9 -99/99 -9.9/9.9
55 200mV...1V custom linear custom linear custom linear custom linear custom linear custom linear
Probe: Custom PT100 - PTC - NTC
56 PT100 custom custom custom custom custom custom
JPT
57 PTC custom custom custom custom custom custom
58 NTC custom custom custom custom custom custom
• TC/LIN input parameters
Input settings
Type of probe,
signal and scale of
main input
I n
In case of non-availability, maximum and minimum limits are set to 0.
In case of custom linearization, test limits for setting LO and HI errors are given by the calibration values.
If these limits are not exceeded, they are taken into consideration as limits LO_S and HI_S.
Max. non-linearity error for
thermocouples (TC),
resistors (PT100) and
thermistors (PTC, NTC).
The error is calculated as deviation from
theoretical value and is expressed as
percentage of full scale (in °C).
S, R range 0...1750°C; error < 0.2% f.s. (t > 300°C) / for other range; error < 0.5% f.s.
T error < 0.2% f.s. (t > -150°C)
B range 44...1800°C; error < 0.5% f.s. (t > 300°C) / range 44,0...999,9; error < 1% f.s. (t > 300°C)
U range -99,9...99,9 and -99...99°C; error < 0.5% f.s. / for other range; error < 0.2% f.s. (t > -150°C)
G error < 0.2% f.s. (t > 300°C)
D error < 0.2% f.s. (t > 200°C)
C range 0...2300; error < 0.2% f.s. / for other range; error < 0.5% f.s.
NTC error < 0.5% f.s.
Tc: J, K, E, N, L error < 0.2% f.s.
PT100, JPT100 and PTC error < 0.2% f.s.
3
81606B_MHW_4T72_0609_ENG
3 / 7
