Page 3
1. Unscrew the outside FADER PLATE SCREWS (B). Do not
touch the INSIDE SCREWS (C).
2. Carefully lift the fader and unplug the CABLE (D).
3. Plug the new fader into the cable and place it back in the
mixer.
4. Screw the fader to the mixer.
The CROSSFADER CURVE BUTTON (19) allows you to adjust the kind
of curve the crossfader has. Depress the crossfader curve button
to make the curve steep and cutting (perfect for scratching).
Release the crossfader curve button to make the curve gradual
and gentle. The CROSSFADER REVERSE SWITCH (31) allows you to
reverse the crossfader so that CHANNEL 2 is controlled by the left
side of the crossfader and CHANNEL 1 is controlled by the right side
of the crossfader.
NONO
NONO
NO
TETE
TETE
TE: When the
CRCR
CRCR
CR
OSSFOSSF
OSSFOSSF
OSSF
ADER REVERSE SWITADER REVERSE SWIT
ADER REVERSE SWITADER REVERSE SWIT
ADER REVERSE SWIT
CHCH
CHCH
CH
(31) (31)
(31) (31)
(31) is activated (moved to the right), only the crossfader
reverses. The Channel Slides, Gain, Kill Switches and
tonal controls do not reverse.
6. PUNCH IN: The PUNCH IN BUTTONS (18, 46) allow you to add a
channel’s signal to the mix when the crossfader is set to the opposite
channel.
7. OUTPUT CONTROL SECTION: The level of the MASTER OUTPUT (3) is
controlled by the MASTER (45) control.
NOTENOTE
NOTENOTE
NOTE: The
RECORD OUT (5) RECORD OUT (5)
RECORD OUT (5) RECORD OUT (5)
RECORD OUT (5) has no level control. The
level is set by the channel slides and the gain controls of
the selected channel. The tonal qualities are set by the
low, mid and high controls of that same channel.
8. TALKOVER SECTION: The purpose of the talkover section is to allow
the program playing to be muted so that the mic can be heard above
the music. The MIC/TALKOVER (14) switch has three settings. When
the MIC/TALKOVER (14) switch is in the left position, the mic and
talkover are both off. When the MIC/TALKOVER (14) switch is in the
center position the mic is on, the MIC INDICATOR (15) will glow, but
talkover is off. When the MIC/TALKOVER (14) switch is in the right
position, the mic and talkover will be on and the volume of all sources
except the Mic input are lowered by 16 dB. MIC LEVEL (17) controls
the level of the MIC. The MIC EQ (16) control allows you to fully adjust
the tone of the MIC.
9. CUE SECTION: By connecting a set of headphones to the HEADPHONE
(47) jack, you can monitor either channel or both together. Move the
CUE SWITCH (42) to the left to monitor CHANNEL 1. Move the CUE
SWITCH (42) to the right to monitor CHANNEL 2. By rotating the CUE
PGM PAN (43) control to the left you will be able to monitor the
assigned cue signal. Rotating to the right will monitor the PGM
(program) output. Use the CUE LEVEL (44) control to adjust the
headphone volume without effecting the overall mix.
10. DISPLAY: The peak hold, dual function DISPLAY (29) indicates either
the MASTER output left and right levels or the channel 1 and channel
2 levels. You can choose the option you want by pressing the
DISPLAY (30) button.
NONO
NONO
NO
TETE
TETE
TE: When the
DISPLADISPLA
DISPLADISPLA
DISPLA
Y (29)Y (29)
Y (29)Y (29)
Y (29) is in the channel 1/
channel 2 display mode, by adjusting the individual channel
gain and tone controls, you can increase or decrease the
signal to match the other channel’s signal. The channel
slides and crossfader have no effect on the display
readings.
Specifications
INPUTS:
DJ Mic..............................................................1.5mV 600 Ohm
Phono.........................................................................3mV 47Kohm
Line.......................................................................150 mV 27Kohm
OUTPUTS:
Amp.................................................................0 dB 1V 400ohm
Max..............................18V Peak to Peak
GENERAL:
Low (Channels 1 - 2)........................................................+ 12dB/-32 dB
Mid (Channels 1 - 2).........................................................+ 12dB/-32 dB
High (Channels 1 - 2).....................................................+ 12dB/-32 dB
Gain (Channels 1 - 2)...........................................................0 to -20dB
Frequency Response....................................20Hz - 20KHz +/- 2dB
Distortion................................................................................0.02%
S/N Ratio...............................................................better than 80dB
Talkover Attenuation..............................................................-16dB
Headphone Impedance.........................................................16ohm
Power Source.................................................115V/230V 50Hz/60Hz 12W
Dimensions...............................10” x 10.24” x 3.3” (254 x 260 x 84 mm)
Weight............................................................................6.25 lbs (3 kg)
