20
PARTS LIST – ALTERNATOR & FRAME
Item Part # Qty Description
1 A187024 1 CRADLE
2 J189176 1 SHIELD, Heat
3 92982 1 DECAL, Danger
4 92665 1 INSULATION, #2-1/4" Thick
5 B1998 1 TANK, Fuel (Incls Item 12 & 13)
6 B4363 1 CAP, with Gauge, Fuel
7 85000 1 CLIP, Insulation
8 93826 1 DECAL, Start Instructions
9 78831B 4 HHMS, M6-1.0 x 60, SEMS
10 83465 4 GROMMET,Tank
11 77395 8 NUT, Flange Lock - M6
12 80270 1 VALVE,Tank
13 78299 1 BUSHING,Tank
14 B2153 9 SCREW, 12-14 x 7/8, Self Driller
15 43116 4 HHCS, M6 - 1.0 x 12
16 51731 2 HHCS, M8 - 1.25 x 50
17 B4135 2 PIN, with Lanyard
18 187104 4 WASHER, Nylon
19 49820 2 NUT, M8 Nylok
20 83083 1 SCREEN, Spark Arrester
21 86307 4 HHMS, 5/16-24 x 3/4"
22 92247 1 HOUSING, Engine Adapter
23 A92531 1 SUPPORT, Engine
24 189160 12 NUT, 5/16-18 Flange Serrated
25 22129 2 WASHER, Lock - M8
26 82857 4 MOUNT,Vibration
27 22531 2 HHCS, 5/16-18 x 1-3/4"
28 92609 2 MOUNT,Vibration
29 22142 2 SCREW, 5/16 - 18 x 3/4"
30 A7433 1 MUFFLER
31 A92731 1 SUPPORT, Engine & Muffler
32 90239 1 GASKET, Muffler
33 B1342G 1 ASSEMBLY, Rotor (Incls Item 34)
34 65791 1 BEARING
35 96796 1 WASHER, Special Flat - M8
36 47481 1 HHCS, 5/16-24 x 10-5/8
37 B1897G 1 ASSEMBLY, Stator
38 20566 1 DECAL, 1-800
39 40976 2 SCREW, M8 - 1.25 x 20
40 92532 1 BRACKET, Muffler
41 66476 2 CAPSCREW, M6 - 1.0 x 12mm
42 186747 1 DECAL, Control Panel
43 92630 1 ASSEMBLY, Control Box
44 J96068 1 SHIELD, Heat
45 14353621 1 WIRE, Ground
46 26850 2 LW, EXT, Shakeproof M6
47 BB3061 2 BOTTLE, Oil
48 81917 1 PIN, Roll 4mm x 10
49 B4986 1 DECAL, Ground
50 186798 2 DECAL, Heat Shield
51 56893 5 CRIMPTITE, 10-24 x 1/2"
52 84132 1 ASSEMBLY, Power Regulator
Item Part # Qty Description
53 67022 1 GROMMET, Rubber
54 66825C 1 CARRIER, Rear Bearing
55 86494 1 SCREW, M6-1.0 x 16 Wing
56 23762 3 WASHER, Shakeproof #10
57 66386 1 ASSEMBLY, Brush Holder
58 66849 2 TAPTITE, M5-0.8 x 16
59 B4871 1 COVER, Bearing Carrier
60 74908 4 TAPTITE, M5-0.8 x 10
61 B4605 2 GRIP
62 66849C 1 TAPTITE, M5-0.8 x 30
63 65795 2 RECTIFIER, Battery Charge
64 66449L 4 BOLT, Stator M6-1 x 190mm
65 22145 4 WASHER, Flat 5/16 - M8
66 22097 5 LOCKWASHER, 1/4" - M6
67 186744 1 MANUAL, Operators
68 BB5586 2 HANDLE
69 52858 4 NUT, Lock M8
70 B186927 1 LEG, Support
71 27007 2 MOUNT,Vibration
72 42909 2 CAPSCREW, M8 - 1.25 x 30
73 93693G 1 AXLE
74 B4966 2 WHEEL
75 22247 2 WASHER,Wheel
76 87005A 2 PIN, Retaining
77 189302B 1 WIRE ASM, #16
78 77282 1 SWITCH, Starter
79 188987 1 BRACKET, Switch
80 188989 1 ASM, Jack, DC
81 22287 2 HHCS, 1/4 - 20 x 3/4"
82 22097 4 LOCKWASHER, 1/4 - M6
83 22127 5 NUT, 1/4 - 20
84 J186704 1 TRAY, Battery
85 B4489 1 BATTERY, 12V 18 AH
86 189302C 1 WIRE ASM, #13
87 185939H 1 WIRE ASM, #55
88 73054 1 DECAL, Fuel Shut-Off
89 77816 2 DECAL, Hot Muffler
90 39253 2 HHCS, M8 - 1.25 x 20
91 A8927 1 MANUAL, Engine
92 52618 2 HHCS, M5 - 0.8 x 12
93 23897 2 WASHER, M5 Flat
94 52856 2 NUT, M5 Flange Hex
95 50190 2 WASHER, Flat 10 GA 0.34 x 1
96 96113 1 WIRE ASM, #13
97 58359 1 LUG, 5/16 #22/18 I-S
98 189198 1 DECAL, Instruction, ES
99 B4177 1 CHARGE, Battery Float
100 189208 3 FUEL STABILIZER, 1oz Tube
101 65787 1 CABLE, Battery Charge
102 37806 1 PLUG, 120V/30 Amp
103 188971 1 EXTENDA PANEL
900 NSP 1 ENGINE
