General ASH12LMACW User Manual

INDOOR UNIT
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
34 Capacitor (Fan Motor) 9704305060
40
Water Seal Plate 9369684005
45 Bracket (Evaporator) 9369372001
61 Decoration Plate 9367731015
63 Front Panel 9368540012
69 Louver 9368560010
69-1 Louver Base-A 9368558017
69-2
Louver Base-B 9368559014
74 Air Filter 9368552008
92 Link Holder 9368563004
108 Base Assy 9369209017
122 Bearing Assy 9368574000
127 Drain Hose
9367695003
146 Evaporator Assy 9372102015
160 Front Drain Pan (kit) 9370932010
160-1 Rear Drain Pan Assy 9369201011
163-2 Thermistor Spring-A 313728262708
164 Fan Motor Assy-IN 9601388012
169 Cross Flow Fan Assy 9368586003
178-1 Rubber (Motor) 9368575007
199 Step Motor 9900020019
233 Power Transformer 9900069018
236 Controller PCB Assy 9704714091
9371190112240 Remote Control Unit
321 Flap 9368544010
329 Coupling Pipe Assy 9369241000
338 Motor Holder-A 9368550004
338-1 Motor Holder-B 9368551001
338-2 Motor Holder-C 9368769000
Ref.
No.
Description
ASH18LMA-W
Ord.
Q'ty
Part No.
Ref.
No.
Description
Ord.
Q'ty
Part No.
ASH18LMA-W
743 Remote Control Unit Case 9305642014
759 Intake Grill-G 9368542030
764 Drain Cap 9367677009
815 Terminal 9306489106
846 Relay G5NB-1A 9701316014
855 Cover Display 9369264016
855-1 Cover Display-B 9369594014
855-2 Cover Display-C 9369683015
938 Control Box Cover-R 9369631009
942 Control Box Cover 9368611002
960 Diffuser Assy 9369346019
963 Fan Guard 9368588007
963-1 Fan Guard Holder 9368554002
998 Bypass Pipe-A 9369238000
999 Bypass Pipe-B 9369239007
735 Distributor Assy 9371178004
522-2 Pinion Gear 9368557003
522-3 Flap Spring 9368612009
557 Diffuser Spring 9368587000
574-1 Evaporator Support-R 9368549008
574-2 Evaporator Support-L 9368548001
684 Motor Base 9368555009
707 Display Cover 9368564001
522-1 Sector Gear 9368556006
18
2004.06.29
401 Wall Hook Bracket 9368579005
408 Louver Link 9368562007
425 Earth Plate 9368580001
428 Screw Cover 9368576011
435 Louver Spring 9368613006
473 Pipe Holder 9368565008
473-1 Cord Holder 9368566005
506 Louver Rod 9368561017
514 Control Box 9368543006
PARTS LIST
385 Indicator PCB Assy 9702307011
