412011.02.08
OUTDOOR UNIT
PARTS
1 Top Panel Sub Assy
2
Front Panel Assy
5 Grip
6 Switch Cover A Assy
3 Cabinet Left Assy
8
Propeller Fan
9 Fan Motor
11
12
Protective Net
9313988128
9313941031
9317588003
9379320016
7 Switch Cover B 9379206013
9313991012
4 Cabinet Right Assy 9379326025
9313990053
9602864003
10
Motor Bracket Assy
9313808013
9313972028
9319157009Emblem Rear
Base Assy13
--
9316885004
9303029022Drain Assy
Ref. Description Part number
12
9
8
13
7
6
5
4
2
1
3
10
11
11
www.enindel.com
