The MM1E’s front-panel bar graph of 10 LEDs measures
%WME (Wood Moisture Equivalent) over two different ranges:
7 to 15% (LOW), and 16 to 35% (HIGH). A slide switch on the
back of the meter requires the user to choose the right range
for the material under test. The same switch functions as the
power switch. Whenever the meter is powered on, the bar
graph momentarily indicates remaining battery life. After
powering on, the meter’s calibration can be checked by
inserting the test pins into holes in the pin protection cover.
The MM1E is powered by a “9V” battery included in the
blister pack.
KEY FEATURES
• 10-LED display
• 7 to 35% measurement range, with separate HIGH
and LOW scales
• Protective cap doubles as calibration checker
• Full Battery and Low Battery indications
WHAT’S IN THE BLISTER PACK
The MM1E comes in a plastic blister pack along with a “9V”
battery, a protective cover for the test pins and this user’s
manual.
4
