Data Review
Press the M button during the hold mode, it will get into the data memory review mode. The LCD
will show MEM symbol.
Press the S button to review data 0 to 20. Data 0 is always at stored the interval time after auto
recording activated. If the data are automatically recorded, the AUTO symbol appears next to MEM
during the review.
DATA STORE
Normal
Press the M button to store the current measurement displayed at Primary Display. The flashing
DATA(01~20) icon becomes steady for 2 seconds, and moves to next storage location.
Auto
If automatically recording is required, press the M button and hold for 2 seconds. The LCD will
show AUTO symbol next to REC symbol. As show AUTO symbol next to REC symbol. As soon as it
reaches 20 data, the system will turn off.
The following record contents will be stored:
1. Irradiation intensity
2. Maximum, Minimum, Average or none
3. Unit
To cancel auto record mode, press the M button again.
ZERO
Zero Adjust
Cover the sensor and press the S button to zero adjust. The Secondary Display will display adjust
value*. Press the S button again and hold for 1 second to clear the adjust value.
*When the adjust value is over the range. The Secondary display will display “-Err”.
Please follow the zero adjust step and do it again.
Memory Clear
In Zero Mode, press the M button to clear data 0 to 20.
UNIT
Unit Function
Press the S button to change the unit, µ 2W cm/ or 2mW/cm
TIME
Time Function
Press the S button to set the interval time of auto recording.
This function allows you to set 9 different time intervals by pressing the S button.
The 9 time intervals are: 1, 2, 5, 10, 30 second or 1, 3, 5, 10 minutes.
MAINTENANCE
Clean the housing: Use soap and water on a damp sponge or soft cloth. Care should be taken to
prevent any liquids or moisture from getting inside the unit.
When the battery is low, the battery symbol will be displayed.
