Getinge MAQUET CARDIOHELP Setup Guide

CARDIOHELP SETUP GUIDE
2
1 Open Safety Bar. Connect Integrated Sensor Cable and
Flow/Bubble Sensor. Connect Venous Probe and place
probe in stand-by position attached to the safety bar.
Cardiohelp System
Preparation and Installation
2 Install the red HLS Module on the Cardiohelp drive.
Step-1
3 Attach sampling lines if desired and close all stopcocks.
Secure all 3 Luer lock connections, but leave the yellow
cap off the De-airing Membrane.
Closed
Closed
Opened
4 Connect the Integrated Sensor Cable to the HLS Module.
