27
2.4.4 Complete the configuration table
Once you have discussed the configuration with the operator:
➮ Complete the configuration table found in the Appendix.
2.4.5 Summary of the jumper settings
Jumper XB1 on the main circuit board
(also see Section 2.4.1 Alarm group)
Alarm contacts Alarm, Fault and
Window Open
(also see Section "Connecting alarm contacts for Alarm, Window Open and Fault" on
the previous page)
Jumper Position Function
XB1
(red)
"Auf"
(open)
With alarm from the alarm group:
Drives in "Auf" (opening) direction
With "Zu/Reset" (close/reset):
Drives in "Zu" (closing) direction
XB1
(red)
"Zu"
(close)
With alarm from the alarm group:
Drives in "Zu" (closing) direction
With "Zu/Reset" (close/reset):
Drives in "Auf" (opening) direction
Jumper Position Function
(1) (black) left Alarm contact acts as make (NO) contact.
(1) (black) right Alarm contact acts as break (NC) contact.
(2) (black) left Window Open contact acts as make (NO) contact.
(2) (black) right Window Open contact acts as break (NC) contact.
(3) (black) left Fault contact acts as make (NO) contact.
(3) (black) right Fault contact acts as break (NC) contact.
